Factory and Safety Pack License x1
Proactive accident protection
The Hanwha Vision Factory & Safety AI Pack provides automatic forklift detection to protect workers from potential hazards and accidents.
Forklift detection
Use your video security system to identify forklifts and people in your workplace and create custom alarms for maximum forklift speed and parking locations.
Exit detection
Detect blocked exits for compliance with OSHA standard 1910.37(a)(3) for obstructed routes.
Slip & fall detection
Set up custom events to trigger when a worker falls down in a user-specified area.
Proximity detection
Measure the distance between detected objects (such as forklifts or people) to generate an alert to warn workers.
Easy to install
Hanwha Vision AI Application Packs are easy to install on P Series AI cameras.
Features:
- Detect people and forklifts
- Line crossing, IVA area(Loitering/Intrusion/Enter/Exit)
- Proximity detection(between people, forklifts, between a person and a forklift)
- Forklift speed detection
- Counting & Heatmap for forklift and people
- Queue events for forklift and people
- Blocked exit detection
- Slip & fall detection
| Application | |
| Type | Camera application |
| Installation | Hanwha Vision open platform v5.x.x or higher |
| Solution | Factory & safety AI pack |
| Version | v2.0 |
| Analytics | |
| Classified object type | Forklift, Person |
| Settings | Sensitivity, Min/max size setting, Exclude area setting |
| BestShot | Support |
| Analytics events | Object detection, Line crossing(Direction), Virtual area(Loitering/Intrusion/Enter/Exit) Slip & fall detection Forklift speed detection Blocked exit detection Proximity detection(Between people, Forklift, Between a person and a forklift) |
| Event action(Cameras event rule setup) | When alarm trigger occurred
|
| Statistics |
|
| Statistics report | Reporting to FTP and Email by schedule XLSX, TXT file for counting, PNG for Heatmap data |
| Supported devices | |
| Cameras | PND-A9081RV/A9081RF, PNV-A9081R, PNO-A9081R, PND-A9081RVX, PNV-A9081RX, PNB-A9001 - Firmware version : 2.21.15 or higher PND-A6081RV/A6081RF, PNV-A6081R, PNO-A6081R, PNB-A6001 - Firmware version : 2.21.08 or higher |
| Integration |
| AI search | Genetec Security Center
Milestone
|
| Application Programming Interface | Hanwha Vision OpenAPI |
| License | |
| Trial version | Supported (60days) model code : AIA-C01FAC-T60/EX |
| Sales version | model code : AIA-C01FAC/EX |
