Hanwha - HV-IE360-12GHX- 980 - Indusrial switch. 8x 10/100/1000T, 2x 100/1000X SFP, 2x 1/10G SFP+, Industrial Ethernet, Layer 3 Switch, PoE++ Support. TAA compliant. Optimized to use with Hanwha network camera products
Part number:
Price:
Allied Telesis industrial switch. 8x 10/100/1000T, 2x 100/1000X SFP, 2x 1/10G SFP+, Industrial Ethernet, Layer 3 Switch, PoE++ Support. TAA compliant. Optimized to use with Hanwha network camera products.
| Total Ports | 12 Ports |
| Copper Ports | 8 x 10/100/1000BASE-T (RJ-45) with PoE++ |
| Fiber Uplink Ports | 2 x 100/1000BASE-X SFP, 2 x 1G/10G SFP+ (with MACsec encryption) |
| Switching Capacity | 60 Gbps |
| Forwarding Rate | 44.6 Mpps |
| Max PoE Budget | 360 Watts |
| PoE Capabilities | Supports PoE (15W), PoE+ (30W), PoE++ (60W & 95W) |
| Physical Dimensions (W x D x H) | 91 x 158 x 153 mm (3.58 x 6.23 x 6.02 in) |
| Weight | 2.2 kg (4.88 lbs) for DIN rail mounting |
| Enclosure & Protection | Aluminium/Stainless Steel, IP30 rated |
| Mounting Options | DIN rail and wall mount (kits included) |
| Input Voltage | 18–57 V DC (PoE sourcing requires ≥ 36V DC) |
| Power Consumption (Max) | 29.9W (no PoE load), 406.5W (full PoE load) |
| Cooling | Fanless design |
Name
Description
Size
Downloads
File
ati-ie360series-datasheet.pdf
0.8mb
File
ati-psu-matrix_0.pdf
0.3mb
File
AE-Document-HV-IE360-12GHX.docx
0.1mb
