Hanwha - NOP-IC2 - Powered by OnCAFE, Intelligent controller supporting (2) doors, featuring (2) Wiegand/OSDP reader ports up to (16 OSDP Readers), (8) High-Precision Supervised Inputs, (4) Form-C relay outputs, (2) Serial Ports, (2) Dedicated Unsupe
Part number:
Price:
- • Supports 2 doors
- • 2 Wiegand/OSDP reader ports (supports up to 16 OSDP readers)
- • 8 high-precision supervised inputs
- • 4 Form-C relay outputs
- • 2 serial ports
- • 2 dedicated unsupervised inputs
- • 1 dedicated RJ-45 10/100 Ethernet port
- • Onboard power monitoring with memory retention
- • Supports up to 1,000,000 cardholders
- • 100,000 offline event cache
- • Handles up to 2,048 inputs/outputs
- • Supports up to 128 readers
- • Advanced elevator control functions
- • Secure operation with TLS 1.3 and AES-256 encryption
- • Power: 12-24VDC
- • Current draw: 350mA
| GENERAL | |
|---|---|
| Weight | 0.6lbs (272 Grams) |
| Regulatory Compliance | CE Compliant, UL 294, 294B, 2610, 1076, ULC / ORD C1076 & 60839-11-1, FCC Part 15 Class A RoHS |
| NETWORK | |
| Operating Temperature | -40°C~+80°C (-40°F~+176°F) |
| Dimensions | 8" x 6" x .88" (203.2mm x 152.4mm x 22.35mm) |
| Network / Host | 1 - Dedicated RJ-45 (10/100 Base-T) Ethernet Port • (2nd Ethernet Port Possible with USB-to-Ethernet Adapter) • IPv4 / IPv6 (Static or DHCP) • Host-Initiated or Controller-initiated Connections • SNMP |
| ONBOARD I/O | |
| Reader Ports | 2 - Reader Ports supporting Wiegand Readers or 16 OSDP Readers Open-Collector Buzzer Output |
| LED Control Signal | (1) LED Control Signal • 2-wire LED support when re-purposing buzzer |
| Unsupervised Inputs | 2 - Unsupervised Inputs for Cabinet Tamper & Power Failure |
| Supervised Inputs | 8 - Supervised or Unsupervised Inputs • Supervised high-precision inputs with hardware and software filtering to eliminate false alarms |
| Outputs | 4 - Form-C Relay Outputs 2A @ 30VDC MAX rating |
| Serial Ports | 2 - Downstream, RS485 Serial Comm Ports • Multi-drop up to 16 IO and/or Reader Interface Boards • 9,600 to 115,200 baud rate • 2-Wire Interface |
| Aux Ports | 1- SD Card 1- Micro USB 2.0 with OTG Support |
| POWER | |
| Input Power (VIN) | 12-24VDC; 350mA typical MAX current |
| Aux Power Output (Fuse Protected) | VIN Passthrough : 1A Max Current |
| Reader Port Power (Fuse Protected) | VIN Passthrough with 500mA Max per port, 12vDC Regulated with 500mA MAX per port or 600mA MAX Combined |
| USB Power | USB 5VDC; 500mA MAX current |
| SECURITY AND CAPACITY | |
| Security | • Encrypted at rest • OSDP Secure Channel with Custom Keys • AES 128/256 - SHA256 Encryption • Open SSL • TLS 1.3 with HSM-signed Root-of-Trust |
| Capacity | • Up to 1 million cards • Up to 128 readers with standard configuration • Configurable 100K+ Event buffer • 300 Access Levels per controller • 50 Access Levels per cardholder • 127 Wiegand card format |
