Hanwha - SMT-2721D - 27" FHD monitor with built-in 64ch IP video decoder, HDMI video out x1 (FHD), Clone and Expand modes, Supported camera resolution: Up to 4K, Maximum decoding performance: 2x8MP@30fps, 12x2MP@30fps, ONVIF, SUNAPI, RTSP, H.265/H.26
Part number:
Price:
• 27inch FHD monitor with built-in video decoder
• Up to 4K camera support
• Up to 64 live video streams
• Multiple screen layouts
• Dual power (HPoE and DC 24V)
• HDMI output for an external monitor
• FCC certified, NDAA compliant, Made in Korea
• Brightness 300 cd/m², Contrast 3000:1
• Designed and tested for 24/7 operations
| Display | |
|---|---|
| Type | LED Monitor |
| Screen Size | 27inch |
| Max. Resolution | 1920x1080 |
| Brightness | 300 cd/m² |
| Contrast Ratio | 3000:1 |
| Aspect Ratio | 16:9 |
| Viewing Angle (H/V) | 178°/178° |
| Display Color | 16.7M |
| Response Time | 12ms |
| Panel Life | 30,000 hours |
| Interface | |
| Video Connectors | HDMI#1 - Internal, Decoder main monitor, HDMI#2 - External, Decoder secondary monitor |
| HDMI Connector | HDMI |
| Available Format | 1280x720@60Hz, 1280 X 1024@60Hz, 1920x1080@60Hz |
| Audio Output Signal | Speakers : 8Ω 1W x 2 |
| Network Ethernet | 1xRJ-45 10/100/1000BASE-T |
| USB USB | 2xUSB 2.0(Mouse,Keyboard), 1xUSB 2.0 (AD Firmware upgrade) |
| On Screen Display | |
| Functions | VESA™ DPMS Compatible |
| Language | English, Spanish, French, Korean |
| General | |
| Electrical Input Voltage | DC24V, HPoE 802.3bt |
| Power Consumption | 31W |
| Environmental Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) |
| Environmental Operating Humidity | 10% ~ 80% (non-condensing) |
| Mechanical Dimensions without Stand (WxHxD) | 624x387x58mm(24.6x15.2x2.3") |
| Weight | 6.5kg(14.3lb) |
| Cabinet Color | Black |
| VESA Mounts Interface | 100x100mm, 200x100mm, 200x200mm |
| Packing Dimension (WxHxD) | 725x500x150mm(28.5x19.7x5.9") |
| Packing Weight | 8.2kg(18.1lb) |
| Decoder | |
| Video Codec | H.265 / H.264 / MJPEG |
| Max. Decoding Performance | 2x8M@30fps, 12x2M@30fps |
| Division (/Monitor) | - Clone mode (HDMI#1) Max. 64, - Expand mode (HDMI#1) Max. 36 (HDMI#2) Max. 25 |
| Layout | Up to 20, Sequence support |
| Audio Codec | G.711 / G.726 / AAC |
| Management | Local UI, Web-Viewer, SSM |
| Time Setting | NTP/Manual |
| Export/Import | Configuration Export/Import |
| Log | Max. 100,000 (System log) |
| Protocol | RTP, RTSP, HTTP, CGI (SUNAPI), ONVIF |
| Security | IP address filtering, User access Log, 802.1x, Encryption, Device certificate(Hanwha Techwin Root CA), Signed firmware |
Name
Description
Size
Downloads
File
DataSheet_SMT-2721D_EN.pdf
0.6mb
File
CAD_SMT-2721D_Common.pdf
0.8mb
