Hanwha - WRT-P-5204W-24TB - Wisenet WAVE Network Video Recorder with 4 Professional licenses, Pre-installed, 24TB
Part number:
WRT-P-5204W-24TB
Price:
Mini-tower form factor Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 24TB raw, 470 Mbps recording B/W, (2) 3.5" HDD, (14th Gen) Intel Core i5, 16GB RAM, 256 GB SSD OS Drive, Windows 10 IoT Enterprise, (2) DisplayPort output, (1) DisplayPort to HDMI adapter included, Dual GbE NICs, Single 550W power supply, Keyboard and mouse included
Features:
- Preloadedandconfigured with Wisenet WAVE video management system & tools
- Upto36TB of Raw Storage
- 470 Mbps of recording throughput
- Includes (4) four WisenetWAVEProfessional licenses
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Supports Wisenet and ONVIF conformant IP cameras
System
| Video Management Software | Wisenet WAVE |
| Included Licenses | 4 x Wisenet WAVE Professional license |
| Recording Bandwidth | Up to 470 Mbps |
| OS Drive Bays | 1 x 256GB M.2 SSD (internally mounted) |
| Data Drive Bays | 3x 3.5" SATA HDDs |
| Data Storage | Up to 36TB raw storage |
| Network Interface | (2) 1GbE RJ45 Ports (1 on-board & 1 PCIe NIC) |
| Processor | 1 x Intel® Core® i5 14th Generation |
| Memory | 16GB DDR4 |
| Operating System | Windows 10 IoT Enterprise LTSC / Ubuntu Linux 22.04 LTS |
| Video Outputs | 2 x DP w/ 1 x DP to HDMI adapter |
| USB Ports | Rear 2x USB 3.2 Gen 2, 2x USB 3.2 Gen 2 Type-C, 2x USB 2.0; Front: 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type-C, 1x USB 3.2 Gen 2x2 Type-C |
| Other Ports | Front: 1x 3.5mm Universal Audio, Back: 1x 3.5mm audio output |
| Keyboard & Mouse | Included |
Mechanical | Form Factor | Tower |
| Color / Material | Black / Metal | |
| Dimensions (HxWxD) | 14.68" x 6.81" x 16.54" (372.9mm x 173mm x 420mm) | |
| Weight | 24 lbs (10.68 kg) | |
| Electrical | Power Supply | 500W 80 Plus Platinum |
| Power Input | 100 ~ 240V AC | |
| Power Consumption | Maximum 500W | |
Environmental | Operating Temperature | 50°F to 95°F (10°C to 35°C) |
| Storage Temperature | -40°F to 149°F (-40°C to 65°C) | |
| Operating Humidity | 20% to 85% (non-condensing) | |
| Certification | UL, cUL, CB, FCC, 80 Plus Gold | |
