Homaxi - NVR401S-8P8 - 8 Channel 1U 1HDD 8POE Network Video Recorders
Part number:
NVR401S-8P8
Price:
8 Channel 1U 1HDD 8POE Network Video Recorders
Features:
- 8CH IP Video input,up to 12M
- H.265+/H.265 dual-stream video compression
- Incoming/Outgoing Bandwidth:80M/80M
- Playback:8CH 1080P@30fps/4CH 4M@30fps/3CH 5M@30fps/2CH 4K@30fps
- Supports mainstream cameras of ONVIF and RTSP protocol
- VGA/HDMI simultaneous video output, maximum resolution of HDMI® is 4K
- AI by Camera:SMD,perimeter protection,face detection,etc.
- NDAA Compliant
| Video & Audio Input | |
| IP Video Input | 8ch |
| Audio input | 1ch, RCA |
| Video & Audio Output | |
| HDMI | 1ch, resolution: 4K(3840×2160)/30Hz,1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA | 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Audio Output | 1ch, RCA |
| Recording | |
| Compression | H.265+/H.265/H.264+/H.264 |
| Resolution | 12MP/8MP/5MP/4MP/3MP/1080P/720P/D1/CIF/QCIF |
| Bit Rate | 64Kbps~10Mbps |
| Playback & Backup | |
| Playback Resolution | 12MP/8MP/5MP/4MP/3MP/1080P/720P/D1/CIF/QCIF |
| Decoding Capability | 1ch@12M 20fps 2ch@8M 30fps 3ch@5M 30fps 4ch@4M 30fps 8ch@1080P 30fps |
| Synchronous Playback | 8ch |
| Playback Mode | Smart Playback/Normal/Time Division/Label/Event |
| Backup Mode | USB Device/Network |
| Advanced Features | |
| Smart Detection by Camera | Area Intrusion, Line crossing, Region Entrance /Region Exiting, Fast Moving, Object Missing, Unattended Object, Loitering Detection, Parking Detection, Face Detection, People Gathering Detection, Blurred detection, Scene change detection, Audio exception detection, SMD, PP |
| Smart Playback | Face detection/Line Crossing/Are Intrution/Motion Detection/Human Detection/Vehicle Detection |
| Cloud Storage | Support |
| Cloud Upgrade | Support |
| Network | |
| Incoming Bandwidth | 80Mbps |
| Outgoing Bandwidth | 80Mbps |
| Ethernet | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Network Compatibility | HTTPs, HTTP, TCP/IP, IPv4, UPnP, RTSP, UDP, SMTP, SNMP, Multicast, NTP, DHCP, DNS, IP Filter, DDNS, FTP, P2P, ONVIF |
| Smart Phone | IOS(iPhone, iPad), Android(Phone, Pad) |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 14TB capacity for each HDD |
| External Interface | |
| POE Interface | 8 independent 10 /100 Mbps PoE Ethernet interfaces |
| USB Interface | Front panel: 1 × USB 2.0 Rear panel: 1 × USB 2.0 |
| Alarm In | N/A |
| Alarm Out | N/A |
| General | |
| Power Supply | DC48V 2.5A |
| Power Consumption | ≤10W(without HDD and POE) |
| Working Environment | 14°F-131°F(-10°C~55°C) / Humidity 10% to 90% |
| Dimension (W×D×H) | 9.84"" × 9.06"" × 1.77"",1U(250 × 230 × 45mm) |
| Weight | 1.7kg |
