AV02CMB-100 - 2 MP Bullet-Style IP Camera - IDIS
Part number:
Price:
- • 1080p (2.1-Megapixel) Resolution
- • 3.6mm Integrated Lens
- • SNAPstream+™ Capability to Reduce Bandwidth without Impacting Image Quality
- • NightView™ for Strong Low Light Performance
- • True Day/Night Functionality with Mechanical IR Cut Filter
- • Enhanced WDR up to 120dB at Full Resolution: See Clearly in Shaded and Bright Light Conditions Simultaneously
- • CorridorView™ Allows 90° Image Rotation for Better Coverage in Hallways and Corridors
- • Privacy Mask, Motion Detection, Bit Rate Control, Multi-Streaming, Multicasting, Forensic Zooming, and Scaling
- • On-Screen Display (OSD)
- • Defog Technology
- • Triple Encoder: H.265/H.264/MJPEG
- • Network Protocols Include SNMP, IPv6, HTTPS, DHCP, 802.1x, and More
- • All-in-One H.265/H.264 PoE Solution
- • Integrated IR LEDs
- • IK-10 Impact-Resistant Housing
- • Outdoor Rated IP66
- • Easily Adjustable 3-Axis Wall Mount
| Camera | |
|---|---|
| Image Sensor | 1080p (2.1MP) CMOS Progressive Sensor |
| Optical Format | 1/2.8" |
| Minimum Illumination (Color - Day Mode) | 0.05 Lux |
| Minimum Illumination (B/W - Night Mode) | 0.005 Lux |
| Full FOV Resolution | 1920 H x 1080 V |
| Scaling | Yes (See Scaling Resolutions Below) |
| IR Illumination | Yes |
| Dynamic Range | 120dB |
| Frame Rates (Single Stream) | Up to 30fps (1080p) |
| Frame Rates (Multi-Stream) | Up to 30fps (1080p) + 20fps (1080p) Up to 30fps (1080p) + 30fps (720p) + 30fps (VGA) |
| Lens | Fixed Iris 3.6mm, F2.0, H-FOV = 85°, V-FOV = 46° |
| Programmability | |
| Optics | Fixed lens |
| Low-Light Performance | NightView™ technology, Smart IR |
| Programmable Shutter Speed | Auto/manual 0.1ms ~ 500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| Backlight Compensation | Auto |
| White Balance Mode | Auto/manual |
| Gain Control | Auto |
| Flicker Control* | 5Hz–255Hz adjustable |
| Image Rotation | CorridorView™ (90°, 180°, and 270° image rotation) + mirror |
| Scaling Resolutions (1080p) | 1920x1080, 1280x720, 960x540, 640x480, 640x360, 320x240 |
| Wide Dynamic Range | Adjustment between WDR and LDR modes |
| Efficiency | SNAPstream+™ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control |
| Defog | Supported |
| Miscellaneous Controls | Programmable brightness, contrast, sharpness, saturation, hue Electronic pan, tilt, zoom (PTZ) |
| Password | 16-digit ASCII character password |
| On-Screen Display (OSD) | Time/date/camera name/custom text |
| Data | |
| Compression Type | H.265/H.264 (MPEG-4, Part 10)/Motion JPEG |
| Bit Rate Control | 64K–8000K |
| Smart Codec | Smart GOP/Smart ROI |
| Transmission Protocols | SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure 10/100Base-T Ethernet network interface, RJ45 |
| Multi-Streaming | 2 x H.265/H.264 stream, 1 x M-JPEG stream |
| Users | Live viewing/Administrator for up to 10 clients |
| Event | |
| Event Trigger | Motion detection, tampering detection |
| Notifications | Send/record message via e-mail/FTP/NAS, record JPG/mp4 |
| Compliance & Listings | |
| Industry Standard | ONVIF Profile S and T conformant |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55032 Class A, EN55024, EN61000-3-2, EN61000-3-3, EN60950 |
| Mechanical | IK-10 (EN62262), IP66 (EN60529) |
| Environmental | |
| Operating Temperature | -20°C (-4°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Electrical | |
| Power Over Ethernet | PoE IEEE 802.3af, Class 3 Total PoE solution (no external power requirement) |
| Power Consumption | 6.6W PoE max (1080p) |
| IR Illuminator | |
| LEDs | 4pcs, Smart IR |
| Projection Distance | 66ft (20m) max |
| Mechanical | |
| Casing | Die-cast aluminum cylindrical (bullet-style) housing IP66 weather proof standard IK-10 impact-resistant |
| Mount | Easily adjustable 3-axis with 360° pan, 90° tilt and 360° z-axis |
| Unit Dimensions | 2.8" H (71.5mm) x 3.39" W (86mm) x 6.8" D (172.8mm) (See Dimensions) |
| Packaged Dimensions | 4.7" H (120mm) x 5.3" W (135mm) x 7.9" L (200mm) |
| Unit Weight | 0.95lbs (0.43kg) |
| Packaged Weight | 1.39lbs (0.63kg) |
| Body Color | AV Costar White (Pantone® Cool Gray 1C) |
Name
Description
Size
Downloads
File
Accessories_Contera.pdf
1.6mb
File
Compare_MegaIP_ConteraIP.pdf
0.4mb
File
ConteraIP_Micro-Bullet.pdf
0.7mb
This is a 2-megapixel (1080p) all-in-one bullet IP camera. It uses a 1/2.8" CMOS sensor and features a fixed lens with a focal length of 3.6mm (F2.0, fixed iris) and an 85-degree horizontal field of view. It has integrated IR illumination with a maximum range of 66 ft (20m) and supports video compression in H.265, H.264, and MJPEG formats. The camera includes a 120dB WDR function, Smart IR, day/night operation, defog, and features like CorridorView image rotation. It is housed in an IK-10 and IP66-rated die-cast aluminum casing. It operates on PoE (802.3af), with max consumption of 6.6W, and within a temperature range of -20°C to +50°C (-4°F to 122°F).
