AV20576RS - Four 5MP Sensors with Remote Setup - IDIS
Part number:
Price:
- • 20MP Resolution
- • Motorized Lens 3.3–6.6mm(x4)
- • Day and night (ICR)
- • True wide dynamic range (WDR)
- • Two-way audio
- • IK10 / IP66
- • PoE+ (IEEE 802.3at Class 4)
- • IR LED (30m / 98.4 ft (6ea))
- • Remotely Adjustable 3-Axis Gimbal
- • NDAA Compliant
- • Supports ONVIF
| Camera | |
|---|---|
| Image Sensor (CMOS) | 20MP (5MP x 4) CMOS Progressive Sensor |
| Optical Format | 1/2.8" |
| Pixel Pitch | 2.0μm |
| Minimum Illumination (Color - Day Mode) | 0.15 Lux |
| Minimum Illumination (B/W - Night Mode) | 0.15 Lux |
| Full FOV Resolution (Total) | 10368 H x 1944 V |
| Full FOV Resolution (Per Sensor) | 2592 H x 1944 V |
| IR Illumination | No |
| Dynamic Range | DOL WDR 120db |
| Frame Rates (At Max Resolution) | 30fps (20MP) |
| Frame Rates (Multi-Stream) | Up to 30fps (20MP) + 30fps (20MP) + 30fps (1.2MP) |
| Lens (x4) | 3.3–6.6mm, F1.8, H-FOV = 42°–96° |
| Programmability | |
| Optics | Remote focus / zoom |
| Low-Light Performance | NightView™ technology |
| Programmable Shutter Speed | Auto/manual 0.1ms ~ 500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| Backlight Compensation | Auto |
| White Balance Mode | Auto/manual |
| Gain Control | Auto |
| Flicker Control | 5Hz–255Hz adjustable |
| Image Rotation | 180° |
| Scaling (20MP) | 2592x1944, 2560x1440, 2304x1296, 2048x1536, 1920x1080, 1600x1200, 1296x972, 1280x960, 1280x720, 800x600, 640x480 |
| Wide Dynamic Range | Adjustment between WDR and LDR modes |
| Efficiency | SNAPstream+ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control |
| Miscellaneous Controls | Programmable brightness, contrast, sharpness, saturation, hue |
| Password | 16-digit ASCII character password |
| On-Screen Display (OSD) | Time/date/camera name/custom text |
| Video | |
| Standard Video Analytics | Motion Detection Camera Tamper Intrusion Detection Line Crossing Loitering |
| Optional Advanced Video Analytics | Object Classification (Person/Vehicle) Object Left/Removed People/Vehicle Counting |
| Accessories | |
| (RS) Standard Model | Power Cable, Alarm Cable |
| (RSIR) IR Model | Cap, Power Cable, Alarm Cable, 2x Audio Cables (In/Out) |
| Data | |
| Compression Type | H.265/H.264 (MPEG-4, Part 10)/Motion JPEG 21 levels of quality |
| Bit Rate Control | 128K–8000K |
| Smart Codec | Smart GOP |
| Network Protocols | SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure |
| Network Interface | 10/100/1000Mbps Ethernet, RJ45 |
| Max Camera Bandwidth | 40Mbps (10Mbps per sensor) |
| Multi-Streaming | 2 x H.265/H.264 stream, 1 x M-JPEG stream (per sensor) |
| Users | Live Viewing/Administrator for up to 10 clients |
| Compliance & Listings | |
| Industry Standard | ONVIF Profile S, G, M, and T conformant |
| Listings | UL62368-1 & CAN/CSA-C22.2 No.62368-1, E489591 |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55032 Class A, EN55035, EN61000-3-2, EN61000-3-3, EN60950, IEC 62471 |
| Mechanical | IK-10 (EN62262), IP66 (EN60529) |
| Event | |
| Event Trigger | Motion detection, tampering detection, alarm in |
| Notifications | Send/record message via e-mail/FTP/NAS, record JPG/mp4 |
| Electrical | |
| Alarm Input/Output | 1 input (wet contact)/1 output (wet contact) |
| Power Over Ethernet (RS) | IEEE 802.3at (PoE+), Class 4 |
| Power Over Ethernet (RSIR) | IEEE 802.3bt (PoE++), Class 5 |
| Auxiliary Power (RS) | 24-48V DC, 24V AC |
| Auxiliary Power (RSIR) | 24V DC, 24V AC |
| Power Consumption (RS) | 25.5W max |
| Power Consumption (RSIR) | 40W max |
| Audio | |
| Streaming | Two-way |
| Compression | G.711 PCM 8 kHz/8 bit |
| Input/Output | Line in (requires amplification) / Line output |
| IR Illuminator (RSIR Models Only) | |
| LEDs | 6 pcs 850nm LEDs |
| Projection Distance | 98.4ft (30m) IR distance (max) / 360° IR angle |
| Environmental | |
| Operating Temperature | -40°C (-40°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Mechanical | |
| Casing | Die-cast aluminum chassis with polycarbonate dome bubble IP66 weather proof standard Impact resistant, IK-10 rated |
| Gimbal (RS) | Remotely adjustable, 3-axis w/360° pan, 135° tilt |
| Gimbal (RSIR) | Remotely adjustable, 3-axis w/360° pan, 90° tilt |
| Unit Dimensions (RS) | Ø 8.8" (223.4mm) x 4.9" H (125.4mm) |
| Packaged Dimensions (RS) | 11.1" W (281mm) x 11.1" L (281mm) x 7.4" H (188mm) |
| Unit Weight (RS) | 5.2lbs (2.36kg) |
| Packaged Weight (RS) | 5.9lbs (2.68kg) |
| On Board Storage (RS) | MicroSDXC slot up to 1TB (card not included) |
| Body Color | Arecont Vision® White (Pantone® Cool Gray 1C) |
Name
Description
Size
Downloads
File
AV20576RS_Brochure
1mb
File
AV20576RS_A&E Specification.pdf
0.1mb
File
AV20576RS_Quick Installation Gudie.pdf
1.4mb
File
AV20576RS_Datasheet.pdf
0.2mb
This is a multi-sensor camera housing four independent 5-megapixel sensors for a total composite resolution of 10368 x 1944 (20MP). Each sensor uses a 1/2.8" CMOS with a motorized varifocal lens offering a focal length range of 3.3–6.6mm (F1.8) and a horizontal field of view from 42° to 96° per sensor. The standard (RS) model does not have integrated IR illumination. It supports video compression in H.265, H.264, and MJPEG formats, with streams managed per sensor. The camera includes 120dB DOL WDR, day/night operation, and remote focus/zoom adjustment for each lens. It is housed in an IK-10 and IP66-rated die-cast aluminum casing. The RS model operates on PoE+ (802.3at) or 24-48V DC/24V AC, with max consumption of 25.5W, and within a temperature range of -40°C to +50°C (-40°F to 122°F).
