AV3226PMTIR-S - MegaView 2 Second Generation Multi-Megapixel Cameras - IDIS
• NDAA Compliant
• Remote Focus/Zoom Motorized P-Iris Lens
• P-Iris Control to Get Best Depth of Field and Image Clarity
• Enhanced WDR™ up to 100dB at Full Resolution: See Clearly in Shaded and Bright Light Conditions Simultaneously
• Privacy Mask, Motion Detection, Flexible Cropping, Bit Rate Control, Multi-Streaming, Multicasting, Forensic Zooming, and Non-Integer Scaling
• Dual Encoder H.264/MJPEG
• CorridorView™ Allows 90° Image Rotation for Better Coverage in Hallways and Corridors
• Binning Mode for Strong Low Light Performance
• True Day/Night Functionality with Mechanical IR Cut Filter and (200ft) IR LEDs
• 8–22mm Telephoto Lens
• Outdoor Rated IP66 and IK-10 Impact-Resistant Housing
• Total PoE Solution (No External Power Required for IR LEDs), PoE and Auxiliary Power: 12–48V DC/24V AC
• Easily Adjustable 3-Axis Wall Mount, Junction Box Included
• SDHC Card Slot for Onboard Storage
• 3MP Resolution
• Network Protocols Include DHCP, QoS, IPv6
| Imaging Sensor | |
|---|---|
| Model | AV3226 (-S model with PMTIR lens) |
| Image Sensor (CMOS) | 3MP |
| Day/Night | True Day/Night with automatic removable IR cut filter |
| Optical Format | 1/3.2" |
| Pixel Pitch | $2.2\mu\text{m}$ |
| Minimum Illumination | |
| Color (Day Mode) | 0.2 Lux |
| Color Binning (Day Mode) | 0.1 Lux |
| B/W (Night Mode) | 0.02 Lux, IR sensitive |
| Resolution & Dynamics | |
| Full FOV Resolution | 2048 H x 1536 V |
| 1/4 Resolution | 1024 H x 768 V |
| Dynamic Range | WDR up to 100dB |
| Maximum SNR | 49dB |
| Frame Rates (At Max Resolution) | 21fps (2048 x 1536) |
| Frame Rates (Cropped) | 30fps (1920 x 1080) 30fps (1280 x 1024) |
| Frame Rates (Binning Mode) | 21fps (1024 x 768) 21fps (800 x 600) 21fps (960 x 540) 21fps (640 x 512) |
| Lens (Telephoto PMTIR) | 8–22mm, 1/2.7", F1.6, RF, RZ, P-Iris, IR corrected |
| H-FOV (PMTIR Models) | 32°–12° |
| Programmability | |
| Optics | Remote focus, remote zoom and P-iris control |
| Low Light Performance | Pixel Binning Mode |
| Programmable Shutter Speed | Controls motion blur, 1ms–500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| Scaling | Non-integer scaling down to 128x96 |
| Flexible Cropping | Resolution windowing down to 1x1 pixel for JPEG and 2x2 pixels for H.264 |
| Backlight Compensation | Multi-matrix white balance |
| Flicker Control | 5Hz–255Hz adjustable |
| Image Rotation | CorridorView™ (90°, 180°, and 270° image rotation) |
| Wide Dynamic Range | Auto adjustment between WDR and LDR modes (WDR models only) |
| Efficiency | SNAPstream™ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control Bandwidth and storage savings by running at 1/4 resolution |
| Sharpness | Selectable enhancement level |
| Miscellaneous | Programmable resolution, brightness, saturation, gamma, tint Electronic pan, tilt, zoom (PTZ) |
| Data Transmission | |
| Compression Type | H.264 (MPEG-4, Part 10) / Motion JPEG 21 levels of quality |
| Network Protocols | HTTP, HTTPS*, IPv4, IPv6, QoS, 802.1x, RTSP, RTP/TCP, RTP/UDP, TFTP, DHCP |
| Network Interface | 100Base-T Ethernet |
| Multi-Streaming | 8 non-identical streams |
| Compliance | |
| Industry Standard | ONVIF Profile S conformant |
| Listings | UL (CB) |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55022 Class A, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 |
| Mechanical | IP66 weather proof standard (EN60529), IK-10 impact-resistant |
| Environmental | |
| Operating Temperature | -40°C (-40°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Electrical & Storage | |
| Alarm Input/Output | General purpose opto-coupled, 1 input/1 output |
| Power Over Ethernet | PoE 802.3af, Class 3 |
| Auxiliary Power | 12–48V DC, 24V AC |
| On Board Storage (-S models) | SDHC slot up to 32GB (card not included) |
| Mechanical | |
| Casing | Die-cast aluminum cylindrical (bullet-style) housing IP66 weather proof standard IK-10 impact-resistant |
| Mount | Easily adjustable 3-axis with 360° pan, 90° tilt and 360° z-axis |
| Dimensions (Unit) | 4.7" H (119mm) x 4.7" W (119mm) x 11.11" D (282mm) |
| Dimensions (Packaged) | 7.1" H (180mm) x 7.1" W (180mm) x 13.5" D (342.9mm) |
| Weight (Unit) | 3.9lb (1.76kg) |
| Weight (Packaged) | 5.2lb (2.35kg) |
This is a 3-megapixel outdoor bullet camera with a telephoto motorized lens. It uses a 1/3.2" CMOS sensor with a true day/night function and features a motorized varifocal lens with a focal length range of 8–22mm (F1.6, P-Iris) providing a horizontal field of view from 32° to 12°. It does not have integrated IR illumination. The camera supports video compression in H.264 and MJPEG formats. The camera includes up to 100dB WDR, day/night operation with a removable IR cut filter, a pixel binning mode, and remote focus/zoom control. It is housed in an IK-10 and IP66-rated die-cast aluminum casing. It operates on PoE (802.3af) or 12-48V DC/24V AC and within a temperature range of -40°C to +50°C (-40°F to 122°F).
