Planet - IGS-501T - IP30 Slim type 5-Port Industrial Gigabit Ethernet Switch
Product Overview
Planet IGS-501T is an IP30 industrial unmanaged 5-port Gigabit Ethernet switch with 5 × 10/100/1000BASE-T RJ45 ports, delivering 10Gbps non-blocking switch fabric and 7.4 Mpps throughput. Features redundant 12-48V DC power input (supporting 24V AC), alarm relay output for power failure, and -40°C to 75°C operating temperature in a slim metal case with DIN-rail or wall-mount.
Key Configuration
• Ports: 5 × 10/100/1000BASE-T RJ45 (auto-negotiation, auto-MDI/MDI-X)
• Switch fabric: 10 Gbps; throughput: 7.4 Mpps @ 64 bytes
• MAC address table: 2K entries; jumbo frame: 9K bytes; buffer: 1M bits
• Power: redundant 12-48V DC (polarity reverse protection) or 24V AC via 6-pin terminal block
• Dimensions: 135 × 87 × 32 mm; weight: 498g
Key Features
Redundant power inputs with alarm relay for failure detection and industrial reliability. Includes ESD/EFT protection (6KV), 9K jumbo frame support, and store-and-forward switching with IEEE 802.3x flow control and back-pressure. Built in slim IP30 metal housing with DIN-rail or wall-mount options, certified FCC Class A, CE, and TAA compliant with full industrial shock, vibration, and drop resistance testing.
Technical Context
The IGS-501T is an unmanaged industrial Gigabit switch designed for reliable operation in harsh environments such as surveillance, automation, and control systems. It delivers a 10Gbps non-blocking switching fabric for full wire-speed performance across all ports. Dual redundant power inputs (12–48V DC or 24V AC) with alarm relay ensure continuous operation and fault notification, while its compact DIN-rail slim design allows easy installation in space-limited control cabinets.
Installation Notes
Compact IP30 metal switch (135 × 87 × 32 mm, 498g) designed for -40°C to 75°C industrial environments. Supports redundant 12–48V DC or 24V AC power via 6-pin terminal block with alarm relay for failure detection. Includes 6KV ESD/EFT protection, low power consumption (4.8–8.3W), and LED status indicators for power, fault, and port activity, optimized for DIN-rail industrial deployments.
| Hardware Specifications | |
| Hardware Version | 3 |
| Copper Ports | 5 x 10/100/1000Base-T RJ45 TP auto-MDI/MDI-X, auto-negotiation |
| Connector | Removable 6-pin terminal block Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2 |
| Alarm | Provides one relay output for power failure Alarm relay current carry ability: 1A @ DC 24V |
| LED | 3 x LED for system and power: – Green: DC Power 1 – Green: DC Power 2 – Green: Power Fault 2 x LED for each copper port – Green: 1000Mbps LNK/ACT – Orange:10/100Mbps LNK/ACT |
| ESD Protection | 6KV |
| EFT Protection | 6KV |
| Power Requirements | 12 to 48V DC, redundant power input with polarity reverse protection, 24V AC power support |
| Power Consumption / Dissipation | 4.8 watts / 16BTU (48V DC) 8.3 watts / 28BTU (24V DC) |
| Installation | DIN rail kit and wall-mount ear |
| Enclosure | IP30 metal case |
| Dimensions (W x D x H) | 135 x 87 x 32 mm |
| Weight | 498g |
| Switch Specifications | |
| Switch Processing Scheme | Store-and-Forward |
| Address Table | 2K entries |
| Buffer Memory | 1M bits on-chip buffer memory |
| Flow Control | Back pressure for half duplex IEEE 802.3x pause frame for full duplex |
| Switch Fabric | 10Gbps |
| Throughput (packet per second) | 7.4Mpps @64bytes |
| Jumbo Frame | 9K |
| Network Cables | 10/100/1000Base-T Cat. 3, 4, 5, 5e, 6 UTP cable [100 meters (max.)] EIA/TIA-568 100-ohm STP [100 meters (max.)] |
| Standards Conformance | |
| Standards Compliance | IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3x full-duplex flow control |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Stability Testing | IEC 60068-2-32 (free fall) IEC 60068-2-27 (shock) IEC 60068-2-6 (vibration) |
| Environment | |
| Temperature | Operating: -40~75 degrees C Storage: -40~75 degrees C |
| Humidity | Operating: 5~90% Storage: 5~90% (non-condensing) |
