The Kendall Howard Triple Fan Panel combines three 115 CFM fans, which together move 345 cubic feet of air per minute. By installing the Triple Fan Panel into your network configuration, you can ensure that the heat produced by your device will be properly and efficiently dissipated, resulting in a cooler environment within your cabinet.
The three 115 CFM high speed fans are pre-installed into a 3U heavy gauge steel panel to provide an out-of-the-box solution. The vented steel panel allows air to move through it with ease while also providing a protective barrier over the face of the fan.
Rack mountable panel easily mounts in any 19″ EIA compliant rack or cabinet. Simply mount using rack screws (and cage nuts if needed) and plug it in to start moving air within your rack configuration.
The Triple Fan Panel includes a 3-tail power cord. This power cable supplies power to all three fans with only using one outlet of your rack mountable UPS or power strip.
Each cooling fan features two threaded ground holes for grounding each fan in installation where specific electrical or network configurations require it.
Features:
- Includes three 115V/115 CFM Fans
- Includes a 3-tail power cord
- Impedance protected
- 19" EIA compliant
- RoHS compliant
- 1-Year Limited Warranty
| Part Number | 1908-3-001-02 |
| Width | 19" |
| Depth | 1.94" |
| Height | 5.22" |
| Weight | 6.50 lbs. |
| Shipping Dimensions | 21" L x 6" W x 6" H |
| Material(s) | Rack Mount Panel: CRS (Cold Rolled Steel) |
| Color/Finish | Rack Mount Panel: Black Powder Coated Finish |
| UPC | 879447001020 |
| Warranty | 1-Year Limited Warranty |
| Shipping Method | FedEx Ground |
| Fan Specifications | Bearing System: Sleeve |
| Voltage | 115 VAC |
| Rated Speed | 3100 RPM |
| Airflow | 115 CFM |
| Noise Level | 49dBA |
| Operating Temperature | 14° F (-10° C) to 158° F (70° C) |
| Power Cord Specifications | Cable Length: 6ft (72 in) |
