Models TLSP-F and TLSP-S are two-way talk/listen speaker/microphones mounted to an 11 gauge stainless steel faceplate. A special designed tone path protects both the speaker and microphone from vandalism. When interfaced with a Louroe Base Station, these units provide 2-way talk/listen using an electret condenser microphone and a 3” speaker, all in the same housing. The TLSP-F/TLSP-S can be wall or ceiling mounted.
Models TLSP-F and TLSP-S can be used with both alarming and non-alarming Louroe Audio Base Stations
Application
In operation, the TLSP provides talk/listen capabilities between the area of coverage and the Louroe Base Station. They are used in:
....Or any area where vandalism is a concern
Features
| Output of microphone (Mic) | Line Level (0 dB, 600W @ 1KOhm) |
| Frequency Response (Mic) | 40 Hz to 15 kHz |
| Current Drain (mic) | 10 mA |
| Speaker | 3”, 2W w/ 70V transformer |
| Faceplate (TLSP-S) | 6”L x 6”W Vandal Resistant |
| Faceplate (TLSP-F) | 7”L x 7”W Stainless Steel |
| Backbox | 6”H x 6”W x 4”D |
| Weight | 4 lbs |
| Shipping Weight | 7 lbs |
