LOUROE - LE-362 - Single Zone Base Station w/Verifact® C Microphone

The ASK-4 #101-C is a single zone audio monitoring system. It is designed for audio monitoring and interfacing with DVR’s, VCR’s or other audio devices that accept line level input. The microphone is inside a small and unusual housing for custom applications. It provides a 30 foot diameter circle coverage. A rubber grommet is included for positioning the microphone element. The desk top audio base station (APR-1) contains a 3" speaker for monitoring live audio and playback from a DVR or VCR. Microphone is pre-amplified and produces line level output.

Kit Contents

• VERIFACT C Electret Condenser Microphone
• Model APR-1 Audio Base Station
• Model AD-1 12Vdc power supply
• Dual RCA cables for connection to DVR/VCR

NOTE: Model APR-1 Base Station can be equipped for 19” rack mounting. Request RM-1935-APR Rack Mount Assembly

Application

The ASK-4 #101C is designed for numerous applications such as:

• Convenience Stores
• Fast Food Restaurants
• Booking Rooms
• Interrogation Rooms
• Car dealership sales contract rooms
• Child Abuse Interviews
• Sleep Disorder Centers
• Speech Therapy Labs
• Cashier Booths
• Casino use in:
  • - soft count rooms
  • - detention centers
  • - medical treatment rooms
  • - cash cages

Features

• Audio output (RCA) to DVR, VCR
• Omni-directional microphone can pick up normal sounds 15' away if wall mounted, or within a 30' +diameter circle if ceiling mounted
• 3" speaker for monitoring live audio and playback +from a DVR or VCR
• 3.5 mm headphone jack for private listening
• Microphone may be mounted up to 1000’ from the APR-1Base Station
