QNAP - KoiBox-100W-US - High-quality Video Conferencing and 4K Wireless Presentation Solution for Business Meeting Rooms, Intel Celeron TGL 6305 , 4GB on-board DDR4 RAM
Part number:
KoiBox-100W-US
Price:

Intel Celeron TGL 6305, 4GB on-board DDR4 RAM, 1 x 2.5" SATA (up to 9.5mm), 1 GbE LAN, 2 x 4K HDMI 1.4b, Wi-Fi 6 & Bluetooth 5.2 with Intel's AX201, 4 x USB 3.2 Gen 2, FanLess



Running the KoiMeeter video conferencing operating system, the KoiBox-100W is the ideal replacement for costly SIP-based conferencing systems and features value-added 4K wireless projection, four-way communication, and local storage features. Creating private meetings with the KoiBox-100W provides higher security and privacy compared with public cloud meetings, and the auto-answering function provides greater convenience in certain usage environments. Besides private meetings, the KoiBox-100W streamlines communication between different platforms by allowing joining Zoom, Skype, Microsoft Teams, Cisco Webex, and Google Meet calls.



Features:

  • 4K wireless projection

    Present with a 4K high-resolution visual experience.



  • Four-way communications

    Multi-point video conferencing with QNAP KoiBox-100W, KoiMeeter,and the KoiMeeter mobile app.



  • Join cloud meetings

    Use cloud-based meeting platforms almost every day? No problem! The KoiBox-100W supports well-known cloud meeting services.



  • Share mobile phone screens

    Scan the QR code on the KoiBox-100W display to quickly share your mobile phone screen.



  • Local storage

    Install a 2.5-inch SATA drive to store meeting videos, audio, and files.



    Note: SSD/hard drive sold separately.

Specifications
Hardware Specs
CPUIntel Celeron dual-core 1.8GHz
System Memory4GB DDR4
Flash MemoryM.2 2242 SSD 30GB
Drive Bay1 x 2.5-inch SATA (HDD/SSD not included)
Gigabit Ethernet Port1 x 1GbE RJ45
Wi-Fi / BluetoothIntel Wi-Fi 6 AX201, 802.11ax, Bluetooth 5.2
HDMI Output1 x HDMI 1.4b output
USB Port4 x USB 3.2 Gen 2 Type-A
IR sensorYes, supports remote controller (RM-IR004)
Buttons1 x Power button
LED IndicatorsPower status
(On: blue, Standby: blue breathing light, Off: red)
Power Supply Unit36W, 100-240V DC, 50/60Hz
Security Slot1x Kensington security slot
Dimensions (H x W x D)45 x 232 x 152 mm
Net Weight1.09 kg (2.4lbs)
Operating Temperature & Relative Humidity0 ~ 40˚C ( 32˚F ~ 104˚F ),5 - 95% RH non-condensing
Name
Description
Size
Downloads
File
Datasheet
0.1mb
