QNAP - QM2-2P-244A - Dual M.2 22110/2280 PCIe SSD expansion card
Part number:
QM2-2P-244A
Price:

Dual M.2 22110/2280 PCIe SSD expansion card (PCIe Gen2 x4), Low-profile bracket pre-loaded, Low-profile flat and Full-height are bundled



For NSA

Use a budget-friendly QM2-2P-244A M.2 PCIe 2.0 expansion card to add NVMe SSD storage to your QNAP NAS.

Features:

PCIe 2.0

  • PCIe Gen2 x4 provides up to 16 Gbps transfer speeds to your QNAP NAS.

Ready-to-use

  • No drivers or extra software are required.

SSD cache & volume

  • Configure SSD caching, an SSD volume, or Qtier (QNAP’s auto-tiering technology) to improve overall NAS performance.

Efficient cooling module

  • Keeps your SSDs at optimal temperature for dependable high performance.

Tool-less design

  • M.2 SSDs can be easily installed in your NAS.

LED indicators & thermal sensors

  • Monitor the real-time status and temperatures of the M.2 SSDs.

For PC/Server

  • Take advantage of unused PCIe slots in your computer to add NVMe SSDs with a budget-friendly QM2-2P-244A M.2 PCIe 2.0 expansion card.

PCIe 2.0

  • PCIe Gen2 x4 supported, providing up to 16 Gbps transfer speeds to your computer.

Ready-to-use

  • No drivers or extra software are required.

Multi OS supported

  • Supports Windows and Linux.

Cooling module

  • Keeps your SSDs at optimal temperature for dependable high performance.

Tool-less design

  • M.2 SSDs can be easily installed in your computer.

LED indicators

  • Monitor the real-time status of the M.2 SSDs.
Connector2 x M.2 22110 or 2280 PCIe (Gen2 x 4) NVMe SSD slots
PCIe and LanesPCIe Gen2 x 4
BracketLow-profile (default). Low-profile flat and Full-height brackets are also included.
Dimensions (L x W x H)147.15 × 68.9 × 20.6 mm
Note [NAS]Recommended models (please update your NAS to latest version)

Please check the M.2 SSD compatibility list and QM2 Installation Guide
Note [PC]Note:
The system BIOS and Operating System (OS) must be capable of supporting a PCIe NVMe SSD. Please refer to the technical manual of your system or consult with the vendor.
