QNAP - QMiroplus-201W-US - QNAP QMiro-201W: WiFi Mesh Tri-band home SD-WAN Router & QNAP Tower NAS 2 bay Intel Gemini Lake J4125 4C, 2 x SATA 3Gb/s 2.5", 4GB DDR4 RAM
QNAP - QMiroplus-201W-US - QNAP QMiro-201W: WiFi Mesh Tri-band home SD-WAN Router & QNAP Tower NAS 2 bay Intel Gemini Lake J4125 4C, 2 x SATA 3Gb/s 2.5", 4GB DDR4 RAM
Part number:
QMiroplus-201W-US
Price:
Dealers only
Add to Quote/Project Registration
Description Specifications Downloads

To embrace the new normal of remote working, businesses must deploy not only a remote VPN that is quickly accessible by multi-location users, but also a high-speed in-premises wireless network and a smarter file storage solution. The QMiroPlus-201W with QNAP Home Cloud 2.0 Solution combines a Mesh Wi-Fi AC2200 router and 2.5GbE NAS to decomplicate your network settings. With two 2.5-inch SATA drive bays and SD-WAN technology, QMiroPlus-201W integrates multi-cloud environments allowing you to centrally manage and access locally-stored and cloud-based files and data, building next-generation networks for homes and remote working.



Features:



  • Tri-band Wi-Fi

    Supports Mesh Wi-Fi Handover, allowing wide-coverage connectivity. Tri-Band Wi-Fi guarantees smooth and stable Wi-Fi connections via 2.4GHz, 5GHz and dedicated Mesh 5GHz frequencies.

  • NAS / router dual systems

    Supports QTS/QuRouter dual-system with home cloud 2.0 solution for easier NAS applications and routing configuration.

  • Mesh VPN

    Easily and securely connect to your company networks and multi-site VPN using the built-in QNAP SD-WAN solution, QuWAN.

  • Home entertainment center

    Use the QMiroPlus-201W as a home storage and entertainment center with various apps for file management, backup, and multimedia.

  • Data backup and recovery

    HybridMount integrates mainstream cloud services and local caching, allowing you to access cloud-based files as if they were stored locally.

  • 2.5GbE connectivity

    One 2.5GbE host management port and four Gigabit ports for flexible LAN and WAN deployment.

Hardware Spec



Number of Ethernet Ports5
2.5GbE Host Port (RJ45)1
1GbE (RJ45)4
CPURouter: Qualcomm IPQ4019, Quad 4cores ARM Cortex A7@716.8MHz
NAS: Intel Gemini Lake J4125 4cores @2.0Ghz
MemoryRouter: 512MB DDR3
NAS: 4GB DDR4
Flash MemoryRouter: 4MB SPI NOR Flash+4GB eMMC
NAS:4GB eMMC
Wireless Antenna4 Internal Antennas
Wireless Standard802.11a/b/g/n/ac
Wireless Speed RatingAC2200
Wireless Speed 2.4 GHz2.4G (400Mbps): 2x2 Dual Band(20/40MHz)
Wireless Speed 5 GHz5G (867+867Mbps): 2x2 Dual Band(20/40/80MHz), 2x2 Single Band (20/40/80MHz)
Frequency Band 2.4 GHzYes
Frequency Band 5 GHZYes
Wireless Bandwidth20/40/80MHz
Transmit Output PowerDepends on country code
Wireless Antenna Type2 Internal dual band(2.4G/5G) antennas
2 Internal single band(5G) antennas
Antenna Gain 2.4 GHz2.5dBi, 2.6dBi
Antenna Gain 5 GHz4.6dBi, 4.4dBi
Transmission Power24dBm
Wi-Fi 5 (802.11ac)Yes
USB 3.2 Gen 1 port

2

Only for connecting USB dongle storage for NAS extend stroage usage

BluetoothVersion 5
Bluetooth Antenna Gain3.42dBi
ButtonPower(for NAS), Reset, WPS
Power12V DC
Power consumption60W
Dimensions183.5x105x143.5
Weight1.44Kg
Packing weight2.15Kg
Operating Temperature0°C ~ +40°C
Operating Humidity5% to 95% non-condensing
CertificationsJATE / CE / FCC / BSMI / NCC / IC / SRRC / CCC / VCCI / RCM / OFCA
Wi-Fi Mesh(with Tri-Band)
QNAP SD-WAN solution, QuWANYes
Drive Bay2 x 2.5-inch SATA 3Gb/s(Compatible with 6Gb/s SSD/HDD)
Drive Compatibility2.5-inch bays:
2.5-inch SATA solid state drives
2.5-inch SATA hard disk drives



Software Spec



Standards Compliance
  1. IEEE 802.3 Ethernet
  2. IEEE 802.3u 100BASE-T
  3. IEEE 802.3ab 1000BASE-T
  4. IEEE 802.3bz 2.5G/5GBase-T
  5. IEEE 802.3an 10G BASE-T
  6. IEEE 802.1Q VLAN Tagging
  7. IEEE 802.3x Full-Duplex Flow Control



System Status and Management
  1. Device connection status
  2. Device health status
    • System uptime
    • CPU temperature
    • Firmware version detect
  3. Connected Devices
  4. WAN status overview
    • Link up / Link down



Wired Network Management
  1. Customer defined WAN/LAN interface setting for each physical port
  2. Physical interface setting status
  3. WAN/LAN configuration
  4. VLAN configuration
  5. Bridge (port group) configuration
  6. Network port connection status
  7. IEEE 802.1Q virtual LAN (VLAN)
  8. IPv4 / IPv6 routing management
    • Routing table
    • Static table
  9. DDNS
  10. DHCP table



Security
  1. Protocol-based firewall (TCP, UDP, ICMP, TCP+UDP)
  2. Firewall rules based on domain names and IP addresses
  3. Port forwarding and Network Address Translation (NAT)
  4. Support FTP ALG, PPTP ALG and SIP ALG
  5. DMZ



VPN
  1. Secure remote access with L2TP, WireGuard, OpenVPN and QBelt (QNAP proprietary) protocol
  2. Client IP pool configuration
  3. VPN user management
    • User status for QBelt / L2TP / OpenVPN / WireGuard
    • User settings for QBelt / L2TP / OpenVPN / WireGuard
  4. Connection logs
  5. Secure remote access as VPN client with OpenVPN protocol



Access Control
  1. Parental control
  2. Domain Name System (DNS) filtering and content filtering
System Setting
  1. Event logs
  2. Restart, Reset, Backup, Audio Alert
  3. Local account, QNAP ID, Remote management
  4. Diagnostics network status
  5. USB Settings: FTP Server, Device User, USB usage condition



QuWAN SD-WAN Service
  1. Auto multi-site VPN
  2. QuWAN QVPN management
  3. Traffic monitoring using QuWAN Orchestrator
  4. Quality of Service
  5. Edge devices monitor
Performance
  1. 50,000 concurrent sessions
  2. 160 Mbps QBelt VPN performance(multiple tunnels)
  3. 324 Mbps QuWAN performance
  4. Max 1000 QBelt connections support(Need managed through QuWAN)

* Actual performance may vary depending on network conditions and activated applications
