QNAP - QWU-100 - 2 LAN port Wake-On-Wan device, powered with USB type-C or PoE LAN port
Part number:
QWU-100
Price:
With the QWU-100, you can easily overcome issues with configuring and managing wake-up services. The QWU-100 supports Wake on LAN, Wake on WAN, USB 3.2 Gen 1 Type-C, PoE interface, and multiple smart features for you to build a dependable remote wake-up environment.
Features:
- Supports USB Type-C interface for convenient power installation.
- The PoE interface provides both data connection and power to devices, achieving convenience and cost-effectiveness.
- Compact form factor with two LAN ports, which is able to manage devices for two networks.
Hardware Spec
| CPU | NXP Cortex-A7 900 MHz |
|---|---|
| System Memory | 512MB |
| Flash Memory | 4GB |
| Ethernet Port (RJ45) | 2 (PoE x1) |
| LED Indicators | Status, LAN x 2 |
| Buttons | Reset |
| Dimensions (H x W x D) | 23 x 101 x 101 mm |
| Package dimensions (H x W x D) | 58 x 140 x 112 mm |
| Net Weight | 0.28 kg / 0.62 lb |
| Gross weight | 0.44 kg / 0.97 lb |
| Operating Temperature & Relative Humidity | -5°C - 45 °C (23°F - 113°F) / 5~95% RH non-condensing, wet bulb |
| Electromagnetic compliance | Class A |
| Power Supply Unit | USB type C, PoE port Notes: PoE needs to comply with IEEE 802.3af-15.4W standard |
| Power Consumption (W) | 3.26 W |
| System Warning | Buzzer |
Software Spec
| Firmware Feature |
|
| Supported browser |
|
Name
Description
Size
Downloads
File
Datasheet
0.2mb
