SPECO - AP300HA - Mullion Proximity Reader- HID, AWID & 125kHz
Mullion Proximity Reader
- Up to 5 in of read range
- Contactless Digital Radio Frequency Identification (RFID) technology
- Compliant with the Wiegand communication protocol
- IP67 compliant, weather resistant
- Tamper resistant
- UL Listed
Technical Specification
|
Technology |
Proximity |
|
|
Frequency |
125 kHz |
|
|
Mounting |
Mullions, including metal door and window frames, as well as flat surfaces |
|
|
Dimensions |
1.7” W × 3.2” H × 0.7” D (43 mm × 81 mm × 18 mm) |
|
|
Weight |
3oz (85g) |
|
|
Certifications |
FCC, ICC, CE, C-Tick, UL Standard 294 |
|
|
IP Code |
IP67 |
|
|
Voltage |
+5 -16 VDC |
|
|
Current Draw |
30mA typical @ 12VDC, 195mA peak |
|
|
Read Range |
Up to 5 inches (126 mm) |
|
|
Cabling |
24 AWG minimum, multiconductor stranded with an overall foil sheild |
|
|
Interface |
Wiegand ABA Track II |
|
|
Operating Temperature |
-40°F to 149°F (-40°C to 65°C) |
|
|
Color Options |
Black and an ivory snap-on cover included standard |
|
|
Audio Tone |
Beeper included standard |
|
|
Indoor & Outdoor Installation |
Electronics sealed in weather- and tamper-resistant epoxy potting |
|
|
Warranty |
Lifetime warranty |
|
|
LED |
Four-state standard (red, green, amber, and off) |
|
|
Technologies Supported |
Pyramid + certain HID® 125-kHz Proximity protocols + certain AWID® 125-kHz |
|
|
Proximity protocols |
