• Extends both power and data 330′ per repeater
• Purchase a second repeater for total run of 1000′
• No external power required
• Compatible with the 802.3af standard
• Supports gigabit network speeds
• Built-in LED status indicator
• Plug and play for easy installation
|
ITEM NO. |
|
|
IPPOERPT |
|
|
|
|
|
Power & Data Input/Output |
|
RJ45 |
|
|
|
|
|
|
Data Link |
|
Pin 1/2 3/6 4/5 |
|
7/8 |
|
||
|
Power Link |
|
Pin 1/2 (+)，3/6 (-) End-Span |
|
||||
|
Transmission Range |
|
2 pieces repeater up to 360 Meters |
|
||||
|
LED Indication |
|
Power: Green, Data link: Yellow/Green |
|
||||
|
POE |
|
IEEE 802.3af Standard, 48V |
12.95W |
|
|||
|
Power Consumption |
|
， |
|
|
、 |
， |
|
|
|
Non-load 1.1W (23mA) 1.44W (30mA) @ 10Mbps 1.92W (40mA) @ |
|
|||||
|
|
|
|
100/1000Mbps |
|
|
|
|
|
Temperature |
|
Operation: 32°F to 131°F, Storage: -4°F to 185°F, Humidity: up to 95% |
|
||||
|
Dimensions |
L x W x H |
|
2.6” x 4.3” x 1” |
|
|
|
|
|
|
， |
， |
|
|
|
||
|
Weight |
|
|
0.4 Lbs. |
|
|
|
|
