SPECO - PBM30 - 30W Contractor Series PA Amplifier UL Listed
Speco Technologies’ UL listed Contractor Series amplifiers are designed for long-running, every day use. They can stand on their own to run a smaller installation, or be incorporated into a much larger job. With RMS power ranging from 30W to 120W, microphone and source-mixing ability, telephone paging interface and music-on-hold capability, there’s practically no job where one of these amplifiers wouldn’t be a perfect fit!
RMS Output Power.............. 30W
Max. Output Power.............. 45W
AC Power Consumption....... 500W
Power Supply ......................AC 120V, 50/60Hz
Zones................................... 1
Speaker Outputs.................. 4/8/16 Ohms, 70/25V
Inputs................................... 2 x Mic (Terminal) 1 x Aux (Stereo RCA)
Frequency Response .......... 70Hz ~ 18KHz (±3dB)
Tone Control ........................ 50Hz ~ 15KHz (±3dB)
THD ..................................... Less than 1% @1KHz
Signal/Noise Ratio............... Microphone: >55dB, TEL: >60dB, Line: >70 dB
Controls ...............................Volume for each source,Tone, TEL Input Level
Telephone............................ TEL in and MoH Out
Indicators.............................Power
Dimensions.......................... 10.75” (W) x 3.5” (H) x 9.5” (D)
Weight ................................. 11.4 lbs.
Listings ................................ UL, cUL, CE, FCC
