• Seven front-selectable 70/25V speaker zones with selectable 70/25V switch
• 24 Volt input for emergency backup power
• Separate bass and treble controls
• Each XLR microphone input has a phantom power toggle
• Mic1 selectable priority paging
RMS Output Power........... 260W
Max. Output Power........... 390W
AC Power Consumption.... 1200W
Power Supply ................... AC 117V, 60Hz, DC 24V, 12A
Zones................................ 7
Speaker Outputs............... 4/8/16 Ohms (non-zoned), 70/25V (zoned)
Other Outputs................... Aux (Stereo RCA), Pre-Amp (RCA)
Inputs................................ 5 x Mic (XLR), 3 x Aux (Stereo RCA), 1 x EQ/Mix (RCA), 1 x TEL (Terminal)
Frequency Response ....... 50Hz ~ 15KHz (±3dB)
Tone Control ..................... Bass ± 10 dB, Treble ± 10dB
THD .................................. Less than 1% @1KHz
Signal/Noise Ratio............ Microphone: >60dB, TEL: >60dB, Line: >70dB
Controls ............................ Volume for each source, Master Volume, TEL Input Level, MoH Volume, Tone, Zone Selector, Phantom Power on/off
Telephone......................... TEL in and MoH Out
Indicators.......................... Power, power level
Dimensions....................... 16.9” (W) x 3.5” (H) x 11.6” (D)
Weight .............................. 29.2 lbs.
Listings ............................. UL, cUL, CE, FCC, RoHS
