SPECO - VID2412CONV - CCTV Power Converter 24VAC into 12VDC 500mA Regulated Output
Part number:
VID2412CONV
Price:
AC to DC12V Power Converter with DC plug cable 500mA Max.
Input power: AC15~26V; DC15~28V.
Output Power: DC12V regulated.
For DC type cameras or video power sources conversion using AC24V for professional CCTV Industry Installation.
|
ITEMS |
|
VID2412CONV |
|
INPUT POWER |
|
AC15~26V; DC15~28V |
|
OUTPUT POWER |
|
DC12V Regulated |
|
OUTPUT CURRENT |
|
500mA |
|
MATERIAL |
|
ABS PLASTIC |
|
CABLE |
|
Input side: 15cm, 22AWG, 2 Pin Terminal Block |
|
|
|
Output side: 15cm, 22AWG, DC Plug |
|
DIMENSIONS |
L x W x H |
2.5" x 1.1" x 1" (Not including cable and connector) |
|
WEIGHT |
|
0.9 Oz. |
Name
Description
Size
Downloads
File
Spec Sheet
0.2mb
File
User Manual
0mb
