Trendnet - TMO-313C2K - 2.5Gbps Ethernet over Coax Adapter (2-Pack)
Part number:
Price:
- • Includes two MoCA® 2.5 (TMO-313C) 2.5Gbps Ethernet over Coax Adapters
- • Supports MoCA® 2.5 over coaxial cables
- • 1 x MoCA Coax: F-Type Female coax input
- • 1 x 2.5Gbps RJ45 LAN port
- • Backward compatible with MoCA 2.0/1.1/1.0 standards
- • Supports up to 16 nodes on one network
- • Bonded MoCA 2.5 channels provide a net throughput of up to 2.5Gbps
- • Designed to connect Ethernet devices to an existing MoCA compliant network
- • Not compatible with DirecTV, DISH Network, AT&T U-verse, or other non-MoCA compliant subscription services
- • NDAA / TAA compliant (U.S. and Canada only)
| Standards | • IEEE 802.3 • IEEE 802.3u • IEEE 802.3ab • IEEE 802.3bz • MoCA 1.1/1.0 • MoCA 2.0 • MoCA 2.5 |
| Device Interface | • 1 x Coax cable in port (female) (Up to 2.5Gbps) • 1 x 2.5Gbps RJ45 LAN port (10Mbps/100Mbps/1000Mbps/2.5Gbps) • Reset button • LED indicators • Power jack |
| Data Transfer Rate | • MoCA 1.1: Single channel up to 225Mbps • MoCA 2.0: Single channel up to 600Mbps • MoCA 2.0: Two bonded channel up to 1.2Gbps • MoCA 2.5: Five bonded channel up to 3Gbps MoCA MAC rate: • 16-node single channel: up to 400Mbps • 16-node 2 channel bonding: up to 800Mbps • 16-node 5 channel bonding: up to 2.5Gbps |
| MoCA Radio | • Max. 16 MoCA 1.1 or 2.0/2.5 devices • Max. 8 MoCA 1.0 devices • Max. transmit power: +3 dBm typical • 1.1/1.0 channels: 8 with 50MHz bandwidth • 2.0 channels: 10 with 100MHz single channel, 225Mhz bonded channel • 2.5 channels: 5 with 100MHz bonded channel • 2.0/2.5 Edge-to-edge frequency: 1125-1675MHz • Default channel: 1150MHz |
| Compatible | • Frontier/Verizon FiOS • Spectrum • Cox Communications • Comcast • Devices with Ethernet port |
| Not Compatible | • DirecTV • DISH Network • Satellite TV • AT&T U-verse |
| Power | • Input: 100 – 240V AC, 50/60Hz, 0.5A • Output: 12V DC, 1A external power adapter • Max. consumption: 12W |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 85% non-condensing |
| Dimensions (per unit) | 112 x 88 x 25mm (4.4 x 3.5 x 1 in.) |
| Weight (per unit) | 116g (4 oz.) |
| Certifications | FCC |
| Warranty | 3-year |
| Package Contents | • 2 x TMO-313C • 2 x Power adapter (12V, 1A) |
Name
Description
Size
Downloads
File
TMO-313C2K - 2.5Gbps Ethernet over Coax Adapter - Datasheet.pdf
0.2mb
File
TMO-313C2K - 2.5Gbps Ethernet over Coax Adapter - QIG.pdf
1.4mb
TRENDnet’s MoCA 2.5 Gbps Ethernet over Coax Adapter (2-pack), model TMO-313C2K, uses your existing coaxial cables to create a high-speed, whole-building Triple Play network in your home or office. These compact coax-to-Ethernet adapters are designed to support MoCA 2.5 deployment for digital TV, high-speed internet and single-access subscription services for voice over IP (VoIP). They are compliant with Multimedia over Coax Alliance (MoCA 2.5) standards and feature improved packet error rate technology, delivering consistent voice and video bandwidth with lowered latency.
