Uniview - DEU1016 - 3U 16 HDDs Mini SAS Disk Enclosure
Part number:
DEU1016
Price:
3U 16 HDDs Mini SAS Disk Enclosure
Features
- 16 SATA HDDs up to 128TB
- 1 x 24Gbps Mini SAS Port
- Power protection from impulse current
- Multistage fan speed and energy saving
- Redundant power supplies
| Storage | |
| HDD | 16 SATA Interfaces |
| Disk Capacity | up to 8TB for each disk |
| External Interface | |
| Back-end Expansion Interface | 1 mini SAS |
| General | |
| Power Supply | 100 ~ 240V |
| Consumption ( with HDD ) | ≤ 100W |
| Working Environment | -10 °C~ 55 °C 5%~95% RH (non-condensing) |
| Weight(Without HDD) | < 10kg(22lb) |
| Dimensions (W×D×H) | 481.6 × 477.1× 130.5mm (18.96” × 18.78” × 5.14”) |
Name
Description
Size
Downloads
File
Datasheet
0.5mb
