Uniview - IPC-D125-PF28 - 5MP Fixed Lens Bullet 2.8mm
Part number:
IPC-D125-PF28
Price:
Uniarch 5MP Fixed Lens Bullet 2.8mm
Features:
Optics
- Day/night functionality
- Smart IR, up to 30m (98ft) IR distance
- 2D/3D DNR (Digital Noise Reduction)
Compression
- Ultra 265, H.265, H.264, MJPEG
- ROI (Region of Interest)
Network
- ONVIF Conformance
Structure
- Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
- Wide voltage range of ±25%
- IK10 vandal resistant
- IP67
- 2-Axis
IPC-D125-PF28 | IPC-D125-PF40 | ||||
| Camera | |||||
| Sensor | 1/3", progressive scan, CMOS | ||||
| Lens | 2.8mm@F2.1 | 4.0mm@F2.1 | |||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | |
| 2.8 | 63.0 | 25.2 | 12.6 | ||
| 4.0 | 90.0 | 36.0 | 18.0 | ||
| Angle of View (H) | 89.1° | 75.0° | |||
| Angle of View (V) | 47.3° | 41.6° | |||
| Angle of View (O) | 94.3° | 81.1° | |||
| Adjustment angle | Pan: 3° ~ 360° | Tilt: 0° ~ 75° | |||
| Shutter | Auto/Manual, 1 ~ 1/100000s | ||||
| Minimum Illumination | Colour: 0.02Lux (F2.1, AGC ON) 0Lux with IR | ||||
| Day/Night | IR-cut filter with auto switch (ICR) | ||||
| Digital noise reduction | 2D/3D DNR | ||||
| S/N | >52dB | ||||
| IR Range | Up to 30m (98ft) IR range | ||||
| Defog | Digital Defog | ||||
| WDR | DWDR | ||||
| Video | |||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | ||||
| H.264 code profile | Baseline profile, Main profile, High profile | ||||
| Frame Rate | Main Stream: 5MP (2592*1944), Max 20fps; 4MP (2560*1440), Max 20fps; 3MP (2304*1296), Max 20fps;1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; | ||||
| HLC | Supported | ||||
| BLC | Supported | ||||
| OSD | Up to 4 OSDs | ||||
| Privacy Mask | Up to 4 areas | ||||
| ROI | Up to 8 areas | ||||
| Motion Detection | Up to 4 areas | ||||
| Network | |||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS, RTMP | ||||
| Compatible Integration | ONVIF (Profile S, Profile T), API | ||||
| Interface | |||||
| Network | 10/100M Base-TX Ethernet | ||||
| General | |||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | ||||
| Power consumption: Max 4.5W | |||||
| Dimensions (Ø x H) | Ø109 x 81mm (Ø4.3” x 3.2”) | ||||
| Weight | 0.33kg (0.73lb) | ||||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | ||||
| Surge Protection | 4KV | ||||
| Ingress Protection | IP67 | ||||
| Vandal Resistant | IK10 | ||||
| Reset Button | N/A | ||||
