Name: Uniview - IPC2124LR3-F40W-D - 4mp Wifi Bullet Network Camera
Brand: Uniview
SKU: IPC2124LR3-F40W-D

Home — Brands — Uniview — Thermal Cameras — Bullet Series —

Uniview - IPC2124LR3-F40W-D - 4mp Wifi Bullet Network Camera

Part number:

IPC2124LR3-F40W-D

Price:

Dealers only

Add to Quote/Project Registration

Description Specifications Downloads

4MP WIFI Bullet Network Camera

Optics:

Day/night functionality
Smart IR , up to 30 m (98 ft) IR distance
Optical glass window with higher light transmittance
IR anti-reflection window to increase the infrared transmittance
2D/3D DNR (Digital Noise Reduction)

Compression:

Ultra 265,H.265, H.264, MJPEG
Triple streams

Network:

ONVIF Conformance

Structure:

Wide temperature range:-30°C ~ +60°C (-22°F ~ 140°F)
Wide voltage range of ±25%
IP67

IPC2124LR3-F40W-D

Camera

Sensor

1/2.7", 4.0 megapixel, progressive scan, CMOS

Lens

4.0mm@F2.0

DORI Distance

Lens

Detect(m)

Observe(m)

Recognize(m)

Identify(m)

4mm

Angle of view(H)

86.5°

Angle of View (V)

44.1°

Angle of View (O)

106.4°

Shutter

Auto/Manual, 1~1/100000 s

Minimum Illumination

Colour: 0.02 Lux (F2.0 AGC ON)

0 Lux with IR on

Day/Night

IR-cut filter with auto switch (ICR)

Digital noise reduction

2D/3D DNR

S/N

>52dB

IR Range

Up to 30m (98 ft) IR range

Wavelength

850nm

IR On/Off Control

Auto/Manual

Defog

Digital Defog

WDR

DWDR

Video

Video Compression

Ultra 265, H.265, H.264, MJPEG

H.264 code profile

Baseline profile, Main Profile

Frame Rate

Main Stream: 4MP (2560×1440): Max. 15 fps; 2MP (1920×1080): Max. 15 fps;

Sub Stream: 720P (1280×720): Max. 15 fps; Third Stream: 4CIF (704×576): Max. 15 fps

Video Bit Rate

128 Kbps~16 Mbps

OSD

Up to 4 OSDs

Privacy Mask

Up to 4 areas

ROI

Up to 2 areas

Motion Detection

Up to 4 areas


White Balance

Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2

Digital noise reduction

2D/3D DNR

Smart IR

Support

Flip

Normal/Vertical/Horizontal/180°

Dewarping

HLC

Supported

BLC

Supported

Storage

Edge Storage	Micro SD, up to 256 GB
Network Storage	ANR
Network
Protocols	IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP,QoS
Compatible Integration	ONVIF(Profile S, Profile G, Profile T), API
Client	EZStation EZView EZLive
Web Browser	Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Web Browser	Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Wi-Fi
Wireless Standards	IEEE802.11b/g/n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	20 MHz Support
Modulation Mode	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM/HT
Security	64/128-bit WEP, WPA-PSK/WPA2-PSK
Transmit Power	802.11b: 17±1.5dBm @11Mbps 802.11g: 14±1.5dBm @ 54Mbps 802.11n: 12.5±1.5dBm @150Mbps
Receive Sensitivity	802.11b: -90dBm @11Mbps (Typical) 802.11g: -75dBm @54Mbps (Typical) 802.11n: -74dBm @150Mbps (Typical)
Transmission Rate	802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps
Interface
Network	1 RJ45 10M/100M Base-TX Ethernet
Certifications
Certifications	CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15
General
Power	DC 12V±25%
Power	Power consumption: Max 4 W
Dimensions (L × W × H)	161.1 × 62.4 ×62.7 mm (6.3” × 2.5” × 2.5”)
Net Weight	0.25 kg (0.55 lb)
Material	Metal + Plastic
Working Environment	-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
Strorage Environment	-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
Surge Protection	2KV
Ingress Protection	IP67
Reset Button	Supported
Indicator Light	Supported
