Uniview - IPC2318SR-ADF28KM-WP - UNV 8MP Wise-ISP ColorHunter Fixed Bullet Network Camera(2.8mm)
Uniview - IPC2318SR-ADF28KM-WP - UNV 8MP Wise-ISP ColorHunter Fixed Bullet Network Camera(2.8mm)
Uniview - IPC2318SR-ADF28KM-WP - UNV 8MP Wise-ISP ColorHunter Fixed Bullet Network Camera(2.8mm)

Uniview - IPC2318SR-ADF28KM-WP - UNV 8MP Wise-ISP ColorHunter Fixed Bullet Network Camera(2.8mm)

Part number:
IPC2318SR-ADF28KM-WP
Price:
Dealers only
Add to Quote/Project Registration
Description Specifications Downloads

8MP ColorHunter with WiseISP Fixed Bullet Network Camera



Features:

  • High quality image with 8MP, 1/1.8"CMOS sensor and F1.0 large aperture lens
  • 8MP (3840*2160)@20fps; 5MP (3072*1728)@30/25fps; 4MP (2560*1440)@30/25fps; 2MP (1920*1080) @30/25fps
  • Ultra 265, H.265, H.264, MJPEG
  • Colorhunter with Wise‑ISP technology ensures 24‑hour full‑color images
  • 120dB true WDR technology enables clear image in strong light scene
  • Support 9:16 Corridor Mode
  • Built‑in Mic
  • White Light, up to 30m warm light distance
  • Supports 512 GB Micro SD card
  • IP67 protection
  • Support PoE power supply
  • 3‑Axis
CameraDescription
Max Resolution8MP
Sensor1/1.8" CMOS
Min. IlluminationColour: 0.0003 lux (F1.0, AGC ON)
ShutterAuto/Manual, 1 ~ 1/100000s
Adjustment AnglePan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360°
S/N>52dB
WDR120dB
LensDescription
Focal LengthIPC2318SR-ADF28KM-WP:2.8 mm IPC2318SR-ADF40KM-WP:4.0 mm
Iris TypeFixed
IrisF1.0
Field of View (H)IPC2318SR-ADF28KM-WP:111.0° IPC2318SR-ADF40KM-WP:94.2°
Field of View (V)IPC2318SR-ADF28KM-WP:63.0° IPC2318SR-ADF40KM-WP:51.0°
Field of View (D)IPC2318SR-ADF28KM-WP:131.0° IPC2318SR-ADF40KM-WP:111.7°
Lens TypeFixed
DORIDescription
DORI Distance (Lens)IPC2318SR-ADF28KM-WP:2.8mm IPC2318SR-ADF40KM-WP:4.0mm
DORI Distance (Detect)IPC2318SR-ADF28KM-WP:63.0 (206.7ft) IPC2318SR-ADF40KM-WP:90.0(295.3ft)
DORI Distance (Observe)IPC2318SR-ADF28KM-WP:25.2 (82.7ft) IPC2318SR-ADF40KM-WP:36.0(118.1ft)
DORI Distance (Recognize)IPC2318SR-ADF28KM-WP:12.6 (41.3ft) IPC2318SR-ADF40KM-WP:18.0(59.1ft)
DORI Distance (Identify)IPC2318SR-ADF28KM-WP:6.3 (20.7ft) IPC2318SR-ADF40KM-WP:9.0(29.5ft)
IlluminatorDescription
Supplemental LightWarm Light
Illumination Distance (Warm Light)30 m (98.4 ft)
Light On/Off ControlAuto/Manual
VideoDescription
Video CompressionUltra 265; H.265; H.264; MJPEG
H.264 Code ProfileBaseline profile, Main profile, High profile
Frame RateMain Stream: 8MP  (3840*2160),  Max 20fps; 5MP (3072*1728),  Max 30fps; 4MP  (2560*1440),   Max 30fps; 1080P  (1920*1080),  Max 30fps; 720P  (1280*720),  Max 30fps;
Sub Stream: 1080P  (1920*1080),  Max 30fps; 720P  (1280*720),  Max 30fps; D1  (720*576),  Max 30fps; 640*360, Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps;
Video Bit Rate128 Kbps ~ 6144 Kbps
U-codeSupport
OSDUp to 4 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Video StreamDual Streams
ImageDescription
White BalanceAuto; Outdoor; Fine Tune; Sodium Lamp; Locked; Auto2
Digital Noise Reduction2D/3D DNR
Smart IlluminationSupport
FlipNormal; Flip Vertical; Flip Horizontal; 180°; 90°Clockwise; 90°Anti‑clockwise
DewarpingN/A
HLCSupport
BLCSupport
DefogDigital Defog
Image StabilizationN/A
EventsDescription
Basic DetectionMotion Detection; Ultra Motion Detection; Tampering Alarm; Audio Detection; Cross Line (based on Human Body Detection); Intrusion (based on Human Body Detection)
General FunctionWatermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication
AudioDescription
Audio CompressionG.711U; G.711A
Audio Bitrate64 Kbps
Two-way AudioN/A
SuppressionSupport
Sampling Rate8 KHz
StorageDescription
Edge StorageMicro SD, up to 512 GB
Network StorageANR; NAS (NFS)
NetworkDescription
ProtocolsIPv4; IPv6; IGMP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTP; RTSP; RTCP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; SMTP; 802.1x; SNMP; QoS; RTMP; SSL/TLS
Compatible IntegrationONVIF (Profile S, Profile G, Profile T);
API; SDK
User/HostUp to 32 users, 2 user levels: administrator and common user
SecurityPassword Protection; Strong Password; HTTPS Encryption; Export Operation Logs; Basic and Digest Authentication for RTSP; Digest Authentication for HTTP; TLS 1.2; WSSE and Digest Authentication for ONVIF
ClientUNV‑Link;  UNV‑Link Pro; EZStation
Web BrowserPlug‑in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug‑in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
InterfaceDescription
Audio I/ON/A
Alarm I/ON/A
Serial PortN/A
Built-in MicSupport
Built-in SpeakerN/A
WIFIN/A
Network1 x RJ45 10M/100M Base‑TX Ethernet
Video OutputN/A
CertificationDescription
EMCCE‑EMC (EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035)
FCC (FCC 47 CFR part15 B)
SafetyCE LVD (EN 62368‑1)
UL/CUL (UL 62368‑1, CAN/CSA C22.2 No. 62368‑1)
EnvironmentCE‑RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU);
ProtectionIP67 (IEC 60529)
GeneralDescription
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power ConsumptionMax 3.9W
Power InterfaceØ 5.5 mm coaxial power plug
Dimensions206 × 73 × 73mm (8.1” × 2.9” × 2.9”) (L x W x H)
Weight0.48kg(1.06lb)
MaterialMetal
Working Environment‑30 °C ~ 60 °C (‑22 °F ~ 140 °F), Humidity: ≤95% RH (non‑condensing)
Storage Environment‑30 °C ~ 60 °C (‑22 °F ~ 140 °F), Humidity: ≤95% RH (non‑condensing)
Surge Protection4KV
Reset ButtonSupport
Web Client Language13 Languages
English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese, Spanish, Spanish (Europe), Italian
Name
Description
Size
Downloads
File
Datasheet
0.3mb
