Uniview - KIT/NVR301-04LS3-W/4*322LB-ABF28WK-G - 1+4 WiFi Dome Kit, 2.8mm lens
Part number:
KIT/NVR301-04LS3-W/4*322LB-ABF28WK-G
Price:
1+4 WiFi Dome Kit, 2.8mm lense
Features:
NVR301-04LS3-W
- Embedded WiFi Module with high-performance and high stability
- Support CCMP encryption and WPA2-PSK authentication, Support IP cameras with WiFi in access
- Support Ultra 265/H.265/H.264 video formats
- 4-channel input
- Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA synchronous outputs provided
- Up to 1080P resolution recording
- 1 SATA HDD, Up to 6TB for each HDD
- Support cloud upgrade
| Model | NVR301-04LS2-W |
| Video/Audio Input | |
| IP Video Input | 4-ch |
| Network | |
| Incoming Bandwidth | 40Mbps |
| Outgoing Bandwidth | 40Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS |
| Video/Audio Output | |
| HDMI/VGA Output | HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 1080P/960P/720P/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Audio Compression | G.711A, G.711U |
| Synchronous Playback | 4-ch |
| Live View Display | 1/4 |
| Corridor Mode Screen | 3/4 |
| Snapshot | |
| Event Snapshot | 1-ch snapshot, up to D1 resolution |
| Decoding | |
| Decoding format | Ultra 265/H.265/H.264 |
| Live view/ Playback | 1080P/960P/720P/D1/2CIF/CIF |
| Capability | 4 x 1080P@30 |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 6TB for each HDD |
| General Alarm | |
| General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0 |
| RS232 | NA |
| RS485 | NA |
| Alarm In | NA |
| Alarm Out | NA |
| Wi-Fi | |
| Frequency | 2.4GHz |
| Transmission Rate | 150Mbps |
| Wireless Standards | IEEE 802.11b/g/n |
| General | |
| Power Supply | 12V DC Power Consumption: ≤ 9 W( without HDD ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions(W×D×H) | 205mm × 205mm × 47mm (8.1" ×8.1"×1.7") |
| Weight ( without HDD ) | ≤0.58Kg(1.28lb) |
| Certification | |
| Certification | UL CE FCC RoHS WEEE |
