Hikvision - DS-KD-KP - Video Intercom Keypad Module
Part number:
DS-KD-KP
Price:
KD8 Series Pro Modular Door Station
Features:
- Keypad module of modular door station
- Supporting input pin code to open door, call indoor station
- IP65 and IK07 higher protection level
- Backlight compensation behind the keypad buttons
- Easy to use and extend
| Specification | |
| System parameters | |
| Operation system | Linux |
| ROM | / |
| RAM | / |
| Processor | Embedded high performance processor |
| Display parameters | |
| Screen size | / |
| Operation method | / |
| Type | / |
| Resolution | / |
| Video parameters | |
| Lens | / |
| Resolution | / |
| FOV | / |
| Wide dynamic range (WDR) | / |
| Supplement light | / |
| Video compression standard | / |
| Audio parameters | |
| Audio input | / |
| Audio compression standard | / |
| Audio output | / |
| Audio compression bitrate | / |
| Audio quality | / |
| Volume adjustment | / |
| Capacity | |
| User capacity | / |
| Face capacity | / |
| Card capacity | / |
| Linked network camera capacity | / |
| Network parameters | |
| Network protocol | / |
| Wi-Fi | / |
| Bluetooth | / |
| 3G/4G | / |
| Device interfaces | |
| Alarm input | / |
| Network interface | / |
| TAMPER | / |
| Exit button | / |
| RS-485 | 1 |
| USB | / |
| Wiegand | / |
| TF card | / |
| Alarm output | / |
| Lock control | / |
| Door contact input | / |
| General | |
| Button | 12 |
| Installation | Flush mounting, surface mounting |
| Indicator | / |
| Weight | Net weight: 265 g Gross weight: 529 g |
| Protective level | IP65, IK7 |
| Working temperature | -40 °C to 55 °C (-40 °F to 131 °F) |
| Working humidity | 10% to 95% |
| Dimension (W × H × D) | 98.5 mm × 100 mm × 34.2 mm (3.87" × 3.95" × 1.33") |
| Battery | / |
| Application environment | Outdoor |
| Power consumption | 1 W |
Name
Description
Size
Downloads
File
Data Sheet
1mb
File
Quick Start Guide
1.8mb
