Dahua - DH-PFA122-B - Waterproof Junction Box

Part number:
DH-PFA122-B
Price:

Junction Box, Material: Aluminum, Color: Black (compatible with EOL A42AC2Z-B 4MP CVI Bullet), Waterproof Junction Box



Features:

  • Material: Aluminum
  • Color: Black
  • Dimensions (W x D x H): 134.0 mm x 133.50 mm x 56.0 mm (5.28 in. x 5.25 in. x 2.20 in.)
  • Operating Temperature: -40° C to 60° C (-40° F to 140° F)
  • Humidity: 0 to 90% RH
  • Load Bearing: 3.0 kg (6.61 lb)
  • Weight: 0.54 kg (1.19 kg)
  • Ingress Protection: IP66
Model DH-PFA122
General
Material Aluminum
Dimension (WxHxD) 134.0mmx133.5mmx56.0mm (5.28”x5.25”x2.20”)
Pipe Thread G3/4”
Weight 0.54kg(1.19lb)
Load Bearing 3.0kg(6.61lb)
Color White
Protection IP66
Operating Temperature -40ºC~+60ºC(-40℉~+140℉)
Humidity 0~90% RH
Applicable Model Please see “Accessory Selection”
Name
Description
Size
Downloads
File
Data Sheet
0.3mb
