Arecont Vision - AV-CSHPX64T - 2U Server, Windows, 64TB



Part number:
AV-CSHPX64T
Price:

64 Channel Cloud Managed Rack Mountable High Performance Network Video Recorder Server with Windows OS, Dual NIC, and 64TB Storage Capacity



AV Costar ConteraCMR Cloud Managed servers are designed to offer maximum performance and reliability, paired with the powerful features and functionality of the ConteraWS web services platform. ConteraWS web services allows you to centralize user management, monitor the health of your recording system, and take advantage of time saving feature like online export and video or clip file sharing. Simply enable ConteraWS on your recorder, and then connect using the ConteraWS web client to manage recorder configurations and user access.



Features:

  • Cloud Management with ConteraWS
  • ConteraVMS Ready
  • Cloud Video Export and Sharing
  • 64TB Storage Capacity
  • 4 Removable Hard Disk Drives (HDDs)
  • Windows OS
  • 64 Max Channel Count
  • IP Channel Upgrades
  • Solid State OS Drive (SSD)
  • DVD-ROM Drive
  • Intel Core i7 Processor
  • Dual NIC
  • 2U Rack Mountable
  • 3-Year Hardware Warranty
  • 1-Year Advanced Replacement
General
Keyboard and MouseIncluded
DVD DriveYes
Operating TemperatureMax temperature: 104°F (40°C)
OS Drive ConfigurationDedicated Solid State Drive
Maximum Storage Configuration
JBOD80TB
RAID80TB (70TB Usable)2
ProcessorIntel® i7
Rack MountInstallation kit and rack slide kit included
Warranty3 Years, 1-year advanced replacement
Electrical
Input Voltage
Standard650W (100V–240V auto switching)
Redundant875W (100V–240V auto switching)
Power Consumption
JBOD160W max
RAID175W max
Compliance
IP Camera SupportArecont Vision / ONVIF Profile S / RTSP
CertificationETL (Intertek) certified
CoOMade in the USA
