Arecont Vision - AV02CMB-100 - 1080p H.265/H.264 All-in-One True Day/Night Indoor/Outdoor Bullet-Style IP Camera

1080p Contera Outdoor Micro Bullet 1920x1080 H.265/H.264/M-JPEG, WDR 120dB, NightView, SNAPstream+, 3.6mm Lens, 30fps, IR, Defog, IP66, IK-10, Onvif, PoE

Part number:
AV02CMB-100
Price:

For clear color images in low-light, NightView offers strong low-light sensitivity for capturing details in extremely poor-lit scenes, and is further enhanced by built-in Smart IR LED illumination that automatically adjusts output in response to the distance of an object in view to prevent over-exposure when the object is very close to the camera. Arecont Vision was the first to bring H.264 to the mainstream market and recently developed SNAPstream (Smart Noise Adaptation and Processing) technology for reducing bandwidth without impacting image quality. Today we are proud to offer our next generation H.265 with SNAPstream+ smart codec capable of delivering high quality video while saving over 50% of the data rate to reduce or prevent strain on the network.



Features:

  •  1080p (2.1-Megapixel) Resolution
  •  3.6mm Integrated Lens
  •  SNAPstream+™ Capability to Reduce Bandwidth without Impacting Image Quality
  •  NightView™ for Strong Low Light Performance
  •  True Day/Night Functionality with Mechanical IR Cut Filter
  •  Enhanced WDR up to 120dB at Full Resolution: See Clearly in Shaded and Bright Light Conditions Simultaneously
  •  CorridorView™ Allows 90° Image Rotation for Better Coverage in Hallways and Corridors
  •  Privacy Mask, Motion Detection, Bit Rate Control, Multi-Streaming, Multicasting, Forensic Zooming, and Scaling
  •  On-Screen Display (OSD)
  •  Defog Technology
  •  Triple Encoder: H.265/H.264/MJPEG
  •  Network Protocols Include SNMP, IPv6, HTTPS, DHCP, 802.1x, and More
  •  All-in-One H.265/H.264 PoE Solution
  •  Integrated IR LEDs
  •  IK-10 Impact-Resistant Housing
  •  Outdoor Rated IP66
  •  Easily Adjustable 3-Axis Wall Mount



Programmability



Optics



Fixed lens



Low-Light Performance

NightView™ technology







Smart IR



Programmable

Auto/manual 0.1ms ~ 500ms



Shutter Speed







Motion Detection

Real-time, 1024 detection zones



Privacy Masking

Unlimited



Backlight Compensation

Auto



White Balance Mode

Auto/manual



Gain Control



Auto



Flicker Control*

5Hz–255Hz adjustable



Image Rotation

CorridorView™ (90°, 180°, and 270° image rotation) + mirror



Scaling

1080p

1920x1080, 1280x720, 960x540, 640x480, 640x360, 320x240













5MP

2592x1944, 2048x1536, 1920x1080, 1296x972, 1280x720,







640x480, 640x360, 320x240



Wide Dynamic Range

Adjustment between WDR and LDR modes



Efficiency



SNAPstream+™ (Smart Noise Adaptation and Processing)







Bit rate and bandwidth limitation control



Defog



Supported



Miscellaneous

Programmable brightness, contrast, sharpness, saturation, hue







Electronic pan, tilt, zoom (PTZ)



Password



16-digit ASCII character password



On-Screen Display (OSD)

Time/date/camera name/custom text

Data Transmission

Compression Type

H.265/H.264 (MPEG-4, Part 10)/Motion JPEG

Bit Rate Control

64K–8000K

Smart Codec

Smart GOP/Smart ROI

Transmission Protocols

SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP,



RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure



10/100Base-T Ethernet network interface, RJ45

Multi-Streaming

2 x H.265/H.264 stream, 1 x M-JPEG stream

Users

Live viewing/Administrator for up to 10 clients

Name
Description
Size
Downloads
File
Datasheet
0.6mb
