Arecont Vision - AV10115DNAIv1 - Single Indoor Box-Style Compact IP Camera
Arecont Vision AV10115DNAIv1 is a single indoor box-style compact IP camera featuring dual sensor technology: a 3MP WDR sensor and a 1.2MP black-and-white sensor for strong performance in low light and high contrast lighting conditions. The camera supports optional True WDR up to 100dB at full resolution, dual encoder H.264/MJPEG, and offers Day/Night functionality with a removable IR cut filter.
Key Configuration
- • Dual sensor: 3MP WDR + 1.2MP B/W
- • Optional True WDR: up to 100dB at full resolution
- • Compression: dual encoder H.264/MJPEG
- • Power: PoE and auxiliary 12–48V DC / 24V AC (auxiliary power not available for dual sensor model)
- • Form factor: single indoor box-style compact IP camera
Key Features
• Small size for flexible mounting options; many lenses to choose from
• Binning mode for strong low light performance (on 3MP, 5MP, and 10MP models)
• True Day/Night functionality with removable IR cut filter
• Day/Night, color-only or auto-iris options
• Privacy mask, motion detection, flexible cropping, bit rate control
• Multi-streaming and forensic zooming
• Casino Mode™ in 1080p models (maintains 30fps or higher)
• Use with Arecont Vision housings or as a standalone camera (dual sensor model incompatible with D4 series housings)
• Reduced overall system cost
Installation Notes
Product type: single indoor box-style compact IP camera. Small size for flexible mounting options. The dual sensor model is incompatible with D4 series housings. Use with Arecont Vision housings or as a standalone camera. Power: PoE and auxiliary 12–48V DC / 24V AC (auxiliary power not available for dual sensor model).
| Data | |
|---|---|
| Compression Type | H.264 (MPEG-4, Part 10) / Motion JPEG 21 levels of quality |
| Network Protocols | RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP |
| Network Interface | 100Base-T Ethernet |
| Multi-Streaming | 8 Non-identical streams |
| Programmability | |
| Features | • Wide dynamic range switch control • Binning Mode (AV3115, AV3116, AV5115, AV10115) • Flexible cropping • On-camera real-time motion detection and privacy mask with 1024 detection zones • Backlight compensation • Auto multi-matrix white balance • 50/60Hz selectable flicker control • Electronic pan, tilt, zoom (PTZ) • Electronic image flip: 180° rotation • Resolution windowing down to 1×1 pixel for JPEG and 2×2 pixels for H.264 • Programmable shutter speed to help control motion blur • Casino Mode™ in 1080p Models (Maintains 30fps or Higher) • MoonLight™ Mode: extended exposure and noise cancellation • Programmable resolution, brightness, saturation, gamma, sharpness, tint • Simultaneous delivery of full field-of-view and zoomed images • Bandwidth and storage savings by running at 1/4 resolution • Bit rate and bandwidth limitation control |
| Compliance & Listings | |
| Industry Standard | ONVIF Profile S and PSIA Conformant |
| Listings | UL (CB) |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55022 Class A, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 |
| Electrical | |
| Input/Output | General purpose opto-coupled |
| Power Over Ethernet (PoE) | PoE 802.3af, Class 3 |
| Auxiliary Power | 12–48V DC, 24V AC (AV3236 is PoE only) |
| Power Consumption | 4.5 Watts (DC Power) |
| Environmental | |
| Operating Temperature | -5°C (23°F) to +45°C (113°F) |
| Humidity | 0% to 90% (non-condensing) |
| Stable Image Temperature | 0°C (32°F) to +50°C (122°F) |
| Storage Temperature | -20°C (-4°F) to +60°C (140°F) |
| Mechanical | |
| Casing | Die-cast aluminum chassis C/CS lens mount |
| Dimensions | |
| Unit (w/o lens) | 3" W (76 mm) × 1.25" D (31.7 mm) × 2.5" H (63.5 mm) |
| Packaged | 4" W (102 mm) × 4" L (102 mm) × 3.7" H (94 mm) |
| Weight | |
| Unit (w/o lens) | 5.8 oz (164 grams) |
| Packaged | 0.7 lbs (0.318 kg) |
