Dahua - DH-IPC-PDBW5831N-B360 - Multi-sensor 4x2MP IP Dome 2.7-12mm motorized IR
Part number:
DH-IPC-PDBW5831N-B360
Price:

The Dahua DH-IPC-PDBW5831N-B360 Multi-sensor Dome Camera features four (4) 1/2.8-in. 2 MP Progressive-scan STARVIS CMOS Sensors each with a 2.7 to 12 mm motorized lens. Each sensor can be positioned and configured independently of the others allowing flexible, multi-directional video surveillance that replaces multiple single-sensor cameras and is ideal for monitoring large areas. The camera offers Wide Dynamic Range, a True Day/Night IR Cut filter, IP67 Ingress protection and operation in extreme temperatures to deliver superior images in all lighting and environmental conditions.



Features:

  • Four (4) Independent 1/2.8-in 2 MP STARVIS qCMOS Sensors
  • Flexible Multi-directional IR Dome with four (4) 2.7 mm to 12 mm Motorized Zoom Lenses
  • Dual-strem Encoding per Channel
  • Smart H.265+ and Smart H.264+ Dual Codec
  • 2 MP at 25 fps Maximum Resolution per Sensor
  • Starlight Technology for Low Light Sensitivity
  • Ultra Wide Dynamic Range (Channel 1) and True Day/Night (ICR)
  • Intelligent Video System
  • Maximum IR LED Distance 30 m (98 ft)
  • IP67 Ingress Protection and IK10 Vandal Resistance
  • 5-year Warranty (for products sold through an authorized Dahua dealer)

Camera

Image SensorFour (4) 1/2.8-in. 2 MP STARVIS™ CMOS
Effective Pixels1920(H) x 1080(V), per sensor
RAM/ROM1024 MB/128 MB
Scanning SystemProgressive
Electronic Shutter SpeedAuto, Manual, 1/3 s to 1/100000 s
Minimum IlluminationColor: 0.005 lux at F1.8 (1/3 s, 30 IRE)
Color: 0.06 lux at F1.8 (1/30 s, 30 IRE)
0 lux at F1.8 (IR on)
S/N RatioMore than 50 dB
IR DistanceDistance up to 30 m (98.43 ft)
IR On/Off ControlAuto, Manual
IR LEDsEight (8) total LEDs; Two (2) LEDs per sensor

Lens

Lens TypeMotorized
Mount TypeBoard-in
Focal LengthFour (4) 2.7 mm to 12 mm
Max. ApertureF1.8
Angle of ViewHorizontal: 105° to 44°
Vertical: 54° to 25°
Optical Zoom4x
Focus ControlMotorized
Close Focus Distance0.20 m (0.66 ft)

Network

EthernetRJ-45 (100/1000 Base-T)
ProtocolHTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP
InteroperabilityONVIF, CGI
Streaming MethodUnicast / Multicast
Maximum User Access10 Users /20 Users
Edge Storage

Network Attached Storage (NAS)

Local PC for instant recording

Micro SD Card Slot, 256 GB maximum

Web ViewerIE
Management SoftwareSmartPSS², DSS, DMSS
Mobile Operating SystemIOS, Android
Name
Description
Size
Downloads
File
Datasheet
1mb
File
Quick Start Guide
1.1mb
