The 16-port managed desktop switch is designed for field transmission applications and for high-definition video. The switch is equipped with a high-performance switching engine, a large buffer, low transmission delay, and high reliability. In addition to the 16 PoE ports, the switch offers two (2) gigabit uplink combo ports with a PoE budget of 240 W. The switch also delivers powerful network management functions including CLI, iLinksView, and Web and network management software based on SNMP.
The switch supports IEEE 802.3bt technology that delivers 90 W via a PoE port and drives high-power infrastructure for smart building systems, safe cities, thin clients, and many more applications. With this standard, the switch can power IT and IoT devices that demand increased power consumption resulting in lower installation and wiring costs.
Features:
- Layer 2 Network Management PoE Ethernet Switch
- Total PoE Budget 240W
- Sixteen (16) 100 Mbps Ethernet Ports and Four (4) 1000 Mbps Uplink Ports (2 RJ45 + 2 Optical Combo)
- Supports IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt Standards
- Supports PoE 2.0: Up to 90 W Output per Red Port, Long-Distance Transmission Up to 820 ft, PoE Watchdog, Intelligent PoE
| Technical Specification | |
| Ethernet Ports | Ports 1 through 16: 10/100 Mbps, RJ45 Ports 17 and 18: 10/100/1000 Mbps (uplink), RJ45 Ports 17 and 18: SFP 1000 Mbps (uplink combo) |
| PoE Power Consumption | Ports 1 and 2: ≤ 90 W (IEEE802.3bt) Ports 3 through 16: ≤ 30 W (IEEE802.3at) Total Power Consumption: ≤ 240 W |
| PoE Protocol | PoE (IEEE802.3af), PoE+ (IEEE802.3at), Hi-PoE, PoE++ (IEEE802.3bt) |
| PoE PIN Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-); |
| PoE Management | Power consumption management Power on and power off Power down for overload Green PoE Legacy support |
| PoE Transmission Distance² | 250.0 m (820.21 ft) |
| Switching Capacity | 8.8 Gbps |
| Packet Forwarding Rate | 5.36 Mpps |
| Packet Buffer Memory | 2.75 Mb |
| MAC Table Size | 4K |
| Standards Compliance | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z |
| Power Input | 100 VAC to 240 VAC |
| Power Consumption | Idle: 10 W PoE Full Load: 240 W |
| Operating Temperature | –10° C to 55° C (14° F to 131° F) |
| Operating Humidity | 10% to 90%, Relative |
| Electrostatic Discharge | Air Discharge: 8 kV Contact Discharge: 6 kV |
Surge Protection Dimensions (L x W x H) | Common Mode: 4 kV Differential Mode: 2 KV Class B Electromagnetic Compatibility Standard |
| Product | 440.0 mm x 300.0 mm x 44.0 mm (17.32 in. x 11.81 in. x 1.73 in.) |
| Packaging | 527.0 mm x 412.0 mm x 110.0 mm (20.75 in. x 16.22 in. x 4.33 in.) |
| Weight | 4.62 kg (10.19 lb) |
| Installation | Rack-mount (rack-mount ears included) |
| Certifications | |
| Safety | EN 62368-1:2014 + A11:2017 |
Electromagnetic Compatibility (EMC) | CFR 47 FCC Part 15 subpart B EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014 |
| Service Specification | |
| Spanning Tree | IEEE802.1d (STP); 802.1w (RSTP) |
| VLAN | IEEE802.1Q Standard VLAN |
| Flow Control | Supports IEEE802.3x (full duplex flow control) and back pressure flow control (half duplex) |
| Link Aggregation | Static, LACP |
| Port Mirroring | One-to-One and Many-to-One Port Mirroring |
| Multicast | IGMP snooping based on port |
| DHCP | DHCP Client |
| Security Features | Hardware supports IP and MAC binding based on port, MAC filtering based on port, and IEEE802.1x port authentication |
| Quality of Service | • High and low priority • WRR • 802.1P • DSCP • Priority based on protocol |
