Dahua - DH-TPC-BF3221 - Thermal Network Hybrid Bullet Camera ePoE
The Hybrid Thermal Network camera combines an uncooled VOx 256 x 192 thermal imager with a 2 MP visible-light sensor for cost-effective, long-range surveillance in a rugged all-in-one package. The thermal imager coupled with an athermalized, focus-free lens produces crisp images in total darkness and sees through rain, fog, and snow. The visible imager with an IR illuminator delivers superior video in any lighting condition.
Features:
Thermal Camera
- 256 x 192 VOx Uncooled Thermal Sensor Technology
- Athermalized Lens, Focus-free
- 7 mm Fixed Thermal Lens
- ≤ 50 mK Thermal Sensitivity
Visible-light Camera
- 1/2.8-in. 2 MP Progressive-scan CMOS Sensor
- 8 mm Fixed Lens
- Maximum IR Distance 50 m (164.04 ft)
System Features
- Intelligent Video System with Excessive Temperature Detection
- Active Alarm with Voice Prompt and White Light
- Enhanced Power and Data Transmission Distances (ePoE)
- IP67 Ingress Protection
- Five-year Warranty (for products sold through an authorized Dahua Dealer)
| Technical Specification | |
| Thermal Camera | |
| Image Sensor | Uncooled VOx Focal Plane Detector |
| Effective Pixels | 256 (H) x 192 (V) |
| Pixel Size | 12 µm |
| Thermal Sensitivity (NETD) | < 50 mK |
| Spectral Range | 8 µm to 14 µm |
| Image Setting | Brightness, Sharpness, ROI, AGC, FFC, 3D DNR |
| Color Palettes | 18, including: Whitehot, Blackhot, Icefire, Fusion, Rainbow, Globow, Ironbow1, and Sepia |
| Compression | H.265, H.264, H.264H, H.264B, MJPEG | |
| Frame Rate | Main Stream | |
| Thermal | 1280 x 960, 1024 x 768, 640 x 480, 256 x 192 at 30 fps | |
| Visible | 1920 x 1080, 1280 x 720, 704 x 480 at 30 fps | |
| Sub Stream | ||
| Thermal | 640 x 480, 256 x 192 at 30 fps | |
| Visible | 704 x 480, 352 x 240 at 30 fps | |
| Bit Rate Control | CBR, VBR | |
| Bit Rate | H.264: 640 Kbps to 8192 Kbps | |
| Day/Night | Auto (ICR), Color, B/W | |
| BLC Mode | BLC, HLC, Digital WDR | |
| White Balance | Auto, Manual, Indoor, Outdoor, ATW, Street Lamp, Natural | |
| Noise Reduction | 2D, 3D | |
| Motion Detection | Off, On (4 zones, Rectangular) | |
| Region of Interest | Off, On (4 zones) | |
| Defog | On, Off | |
| Flip | 0°, 90°, 180°, 270° | |
| Mirror | Off, On | |
| Privacy Masking | Off, On (4 areas, Rectangle) | |
| Network | ||
| Ethernet | RJ-45 (10/100 Base-T) | |
| Protocol | HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP | |
| Interoperability | CGI | |
| Streaming Method | Unicast, Multicast | |
| Edge Storage | Network Attached Storage (NAS) Local PC for Instant Recording MicroSD Card Slot (up to 32 GB) | |
| Maximum User Access | 20 Users | |
| User Management | Supports 20 users atone time and users are classified as one of tow groups: administrator or user | |
| Security | Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access | |
| Web Viewer | IE 8 or later | |
| Management Software | DSS Pro, DSS Express, DMSS | |
| Mobile Operating System | IOS, Android | |
| Cybersecurity | Video Encryption, Firmware Encryption, Configuration Encryption, Digest, WSSE, Account Lockout, Security Logs, IP/MAC Filtering, Generating and Importing X.509 Certification, Syslog, HTTPS, 802.1x, Trusted Boot, Trusted Execution, Trusted Upgrade | |
| Image Sensor | 1/2.8-in. CMOS |
| Effective Pixels | 1920 (H) x 1080 (V), 2 MP |
| Electronic Shutter Speed | 1/1 s to 1/30,000 s |
| Minimum Illumination | Color: 0.005 lux at F1.9 B/W: 0.0005 lux at F1.9 0 lux with IR On |
| IR Distance | 50.0 m (164.04 ft) |
| IR On/Off Control | Auto, Manual |
| IR LEDs | One (1) |
