Experience the superior clarity of 5MP video and the range of a 360° panoramic fisheye camera. The camera delivers high quality images with crisp details and accurate color rendition, even under complex lighting conditions thanks to True WDR (120 dB). The compact camera replaces multiple single-sensor cameras providing a higher return on investment for your security dollars, and holds the EN 50155 Shock and Vibration Certification making it the perfect choice for all rolling stock.
Features :
- 1/2.7-in. 5MP Progressive-scan CMOS Sensor
- Triple Stream Encoding
- M12 D-Coding Aviation Connection
- Smart H.265+ and Smart H.264+ Dual Codec
- 5 MP (2592 x 1944) at 30 fps Maximum Resolution
- 1.4 mm Fixed Lens
- True Wide Dynamic Range (120 dB)
- Built-in Microphone
- EN 50155 Shock and Vibration Certification
- IP67 Ingress Protection and IK10 Vandal Resistance
- 5-year Warranty (for products sold through an authorized Dahua dealer)
| Camera | |
| Image Sensor | 1/2.7-in. 5 MP Progressive-scan CMOS |
| Effective Pixels | 2592(H) x 1944(V) |
| RAM/ROM | 512 MB / 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto, Manual; 1/3 s to 1/100,000 s |
| Minimum Illumination | Color: 0.006 lux at F2.0 |
| S/N Ratio | > 56 dB |
| Lens | |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 1.4 mm |
| Max. Aperture | F2.0 |
| Angle of View | Horizontal: 180° Vertical: 180° Diagonal: 180° |
| Iris Type | Fixed |
| Close Focus Distance | 0.20 m (0.70 ft) |
