Dahua - N54B5N4 - 4K 32CH 1.5U Dual NIC NVR 4TB Included
Part number:
N54B5N4
Price:

Dahua’s Pro Series network video recorders offer excellent performance and high recording quality for IP video surveillance applications. For applications where details are critical for identification, this professional NVR provides a powerful processor with up to 4K resolution. Additionally, the NVR features a mouse shortcut operation menu, remote management and control, center storage, edge storage, and back up storage.


Designed as a cost-effective and easy to install recorder, this NVR is an ideal addition to any security system that monitors public spaces, water conservancy, transportation, city centers, schools, and financial institutions.
The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems with or without a video management system (VMS). Its open architecture supports multi-user access and it is compatible with ONVIF 2.4, enabling interoperability when combined with 4K cameras.



Features:

  • Dual NIC Supports Multi-Address, Fault Tolerance, and Load Balance
  • Smart H.265+ and Smart H.264+ Video Compression
  • Maximum 320 Mbps Incoming Bandwidth
  • Up to 12 MP Resolution for Preview and Playback
  • Two (2) Gigabit Ethernet Connections
  • Support for IPC and UPnP Protocols
  • Customized Live View Layout with Support for Panoramic Displays
  • Intelligent Video System with Business Analytics
  • Compatible with Dahua Smart Motion Detection+ Cameras
  • Five-year Warranty (for products sold through an authorized Dahua Dealer)
System
Main ProcessorEmbedded Quad-core Processor
Operating SystemEmbedded Linux
Audio and Video
IP Camera Input32 Channels
Two-way TalkInput: One (1) Channel, RCA
Output: Two (2) Channels, RCA
Display
InterfaceTwo (2) HDMI Ports:
• HDMI-1: 4K
• HDMI-2: 1080p
Two (2) VGA Ports (1080p)
Native Output ResolutionHDMI-1 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
VGA-1 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
HDMI-2 / VGA-2 1920 x 1080
Maximum DecodingTwo (2) Channels of 12MP at 20 fps
Four (4) Channels of 8MP at 30 fps
Five (5) Channels of 6MP at 30 fps
Six (6) Channels of 5MP at 30 fps
Eight (8) Channels of 4MP at 30 fps
Eleven (11) Channels of 3MP at 30 fps
Sixteen (16) Channels of 1080p at 60 fps
Sixteen (16) Channels of 1080p/720p at 30 fps
Fisheye DewarpingDewarps a single channel at a time
Multi-screen DisplayFirst Screen: 1/4/8/9/16/25/36
Second Screen: 1/4/8/9/16
On-screen DisplayCamera Title, Time, Camera Lock, Motion Detection, Recording
Name
Description
Size
Downloads
File
Data Sheet
0.6mb
