Advanced Linux-Based embedded NVR, 32TB, Supports 16 2.1MP cameras@30fps (1080P) up to 4K, ONVIF, 16 port PoE switch built in, H.264/H.265, HDMI, VGA, 8 Sensor Input, 4 Relay Output, 1ch Audio Input, 1ch Audio Output, Pathfinder Peer to Peer(P2P) remote connection, Event Notifications via Email, Automatic Device Discovery, C3 Central Management Software Up to 128CH, Free Mobile Apps for iPhone, iPad, iPod, Android Smart Phones and Tablets, MAC Compatible Remote Software, System Analysis with Real Time System, Network, and PoE Status Monitoring, Drag and Drop Camera Pla8ement, One Touch Video Backup, Reverse Playback, & Emergency Recording, Simple & Free DDNS Support for Remote Management, Help Menu on Major Functions, Auto & Manual Firmware Upgrade Available, Import/Export Configuration between Multiple DVRs, USB Mouse and GUI Control, PTZ, NDAA, TAA, 5 Year Limited Warranty.
The VMAX IP G4 is an NDAA and TAA compliant, easy to use embedded PoE network video recorder (NVR) that allows you to go from power up to monitoring in minutes! Available with 16 Power over Ethernet (PoE) ports, the NVRs can record and manage single-sensor IP cameras up to 4K resolution and comes with up to 32TB internal storage.
Features:
- Complete installation, setup and camera configuration in minutes!
- CCIP system encryption via TLS protects your surveillance system from out of network attacks
- Record and manage single-sensor IP cameras at real-time 30fps up to 4K (3840×2160), with 160Mbps maximum throughput
- Local power for up to 16 IP cameras via resident PoE+ switch
- DW Witness turns a smartphone or tablet into a surveillance camera
- PathFinder easy end-to-end remote connection with NAT Traversal (STUN/TURN) support
- Automatic device discovery
- Compatible with ONVIF cameras
- 0-32TB storage options
- Transfer real-time data using Real Time Streaming Protocol (RTSP)
- Snapshot Notify: Interval camera image verification sent to an email
- Remote management with C3 CMS for Windows and Mac
- Event camera group recording
- System analysis with real-time system, PoE and network status monitoring
- Event notifications via email, text and C3 CMS and push notifications to mobile devices
- Mobile Application for iOS and Android devices
- Dual-stream recording
| VIDEO | |
|---|---|
| Display Modes | 1, 12, 16, 4, 6, 9, Sequence |
| Display Speed | Up to 30fps per channel |
| Local Video Output Resolution | 1024x768, 1280x1024, 1280x720, 1920x1080, 2560x1440, 800x600, 3840×2160 (4K) |
| Local Video Outputs | True HD, VGA |
| Max Supported Recording Resolution | 4K (3840×2160) |
| Video Compression | H.264, H.265 |
| OS on SSD | N/A |
| Max throughput (Mbps) | 160Mbps |
| Input channels | 16 Channels, 16 PoE channels |
| STORAGE | |
| Raw internal storage options |           |
| RAID Options | No RAID |
| Max HDD Bay | 2 x SATA HDD |
| Maximum Storage | 10TB (DW-VG41610T16P), 12TB (DW-VG41612T16P), 16TB (DW-VG41616T16P), 2TB (DW-VG4162T16P), 4TB (DW-VG4164T16P), 6TB (DW-VG4166T16P), 8TB (DW-VG4168T16P), 20TB (DW-VG41620T16P), 32TB (DW-VG41632T16P), No storage (DW-VG41616P) |
| PERFORMANCE | |
| Alarm in/out | 4 alarm outputs |
| Audio in/out | 1 input, 1 output, 8 inputs |
| Performance features | Camera Color Control, CCIP, Covert Channel, Digital Zoom in live and playback, Import and export settings, PoE built-in, Quick Setup under 3 Minutes, Real-time temp alert |
| Playback Functions | Calendar, Event search, Smart motion search, Thumbnail search, Timeline |
| Playback speed | x1, x16, x2, x32, x4, x64, x8, x99 |
| Post-recording | 0~5 minutes |
| Pre- recording | 0~5 seconds |
| PTZ control | RS485, UTC |
| Recording Modes | Continuous, Emergency, Motion detection, Pre- and post-alarm, Quick backup, Scheduled, Sensor |
| Recording Resolution and Recording Rate | Up to 3840×2160 (4K): 480fps |
| System Operation | Graphical user interface (GUI), Joystick Controller (optional), USB mouse (included) |
| NETWORK | |
| Backup | Local backup via USB, Network backup via CMS |
| Ethernet Ports | 1x 1G Ethernet (RJ45) |
| Firmware Upgrade | CMS over network, FTP, USB |
| Protocol | DDNS, DHCP, RTSP, Static fixed IP, uPNP |
| System recovery after power failure | Auto-reboot and journaling file system |
| Transmission speed live | Up to 3840×2160 (4K): 480fps |
| Network Remote Software | DW VMAX Plus App, C3 CMS, DW Mobile Plus, DW Witness |
| ELECTRICAL | |
| Maximum Power per Port | Up to 30W |
| Power Consumption | 180W total power budget (recorder + PoE ports) |
| Power Requirements | 54V DC, 3.33A |
| Total PoE Power Budget | 150W, 9.37W per PoE port |
| GENERAL | |
| Accessories | Mouse |
| Operating Temperature and Humidity | 10~90% RH, 32~113 °F (0~45 °C) |
| Rail kit | DW-G419RE (optional. Sold separately) |
| Recorder Dimensions (H X W X D) | 14.96" x 10.58" x 1.77" (380 x 268.8 x 45 mm) |
| Serial ports | RS485 |
| USB interface | Yes |
| Warranty | 5 Year Limited Warranty |
| Weight (barebone, HDD not included) | 4.1 lbs (1.85 kg) |
| Certification |     |
| Form Factor | Embedded |
