SECO-LARM - SM-217Q/W - Miniature Surface-Mount Closed Loop Magnetic Contact with concealed screw terminals. 2" Gap. White. Sold in multiples of 10 (price is for 1 pc).
Part number:
SM-217Q/W
Price:
Miniature Surface-Mount Closed Loop Magnetic Contact with concealed screw terminals. 2" Gap. White. Sold in multiples of 10 (price is for 1 pc).
Features:
- Surface-mount magnetic contact
- Screw mount
- ABS plastic case has integrated mounting holes
- Contact reed switch is SPST, deactivated rhodium on gold under-plating, for a long life
- White 2″ (51mm) wide gap for loose-fitting doors and windows
- Lifetime limited warranty
| Loop Type | Closed loop |
| Electrical Configuration | N/O |
| Operation Gap | 2″ (51mm) |
| Terminals | Screw-type |
| Color | White |
| Material – Case | High-impact ABS plastic |
| Contacts | Deactivated rhodium on gold under-plating |
| Contact Rating | 0.75A@24VDC (max.) 1.0A@10VDC (max), 10W (max) |
| Operating Temperature | -15º~+160º F (-25º~70º C) |
| Switch Cycles | 50 Million (0.1mA@5VDC) |
| Switch Dimensions | 2-1/2″ x 9/16″ x 1/2″ (63.5 x 14 x 13 mm) |
| Magnet Dimensions | 2-1/2″ x 9/16″ x 1/2″ (63.5 x 14 x 13 mm) |
| Magnet Type | Alnico 5 |
