SECO-LARM - SSW-113H - Water Sensor
Part number:
SSW-113H
Price:

Water Sensor, detects conductive, non-flammable liquids. For open loop circuits. Sold in multiples of 2 (price is for 1 pc).



Features:

  • Install anywhere water damage may occur
  • Detects conductive, non-flammable liquids
  • For open loop circuits
  • Automatic reset
  • Sold in quantities of two
Loop typeOpen loop
Electrical configurationN.O.
Operating voltage5~24 VDC
Current draw (max.)12VDC: 30mA 24VDC: 50mA
Wire6ft (1.8m) 2C (22AWG)
CaseColor: White Material: ABS
Operating temperature32°~140° F (0°~60° C)
Dimensions2-1/2″x1/2″x1/2″ (64x13x13 mm)
Weight1.6-oz (44g)
