VideoTec - CMSB2200 - Unarmoured blue cable, available by the meter (minimum order 10m): 2 Ethernet cables, 3 power supply wires, 2 coaxial video cable, 15 wires for alarms, relays and telemetry
Part number:
CMSB2200
Price:
Armoured and unarmoured multipolar cables for Pan & Tilt and housings.They are suitable for use in hostile environments.
Features::- Resistant to oil, flame spread and ultra-violet rays
- Prepared for Ethernet, video, I/O and telemetry connections
- Available in an armoured and unarmoured version
- Designed for potentially explosive zones
| GENERAL: |
| Unarmoured black cable: 2 Ethernet cables, 3 power supply conductors, 2 coaxial video cables, 15 shielded I/O cables |
| MECHANICAL: |
| Unarmoured cable |
| External diameter: 18.6mm (0.73in) ± 0.35mm (0.01in) |
| Minimum bending radius: 186mm (7.3in) |
| Colour: Black (RAL9005) |
| Colour: Black (RAL9005) |
| Type of laying: fixed installation |
| ELECTRICAL: |
| Power Supply |
| • Number of conductors: 3 |
| • Section: 1.5mm² (15AWG) |
| • Working voltage: 300V max |
| NETWORK |
| Ethernet cable |
| • Number of cables: 2 |
| Section: 4x2x0.22mm² (24AWG) |
| • Shielded cables |
| ENVIRONMENT: |
| Temperature: from -40°C (-40°F) up to +85°C (+185°F) |
| CERTIFICATIONS: |
| UL Style 20233 |
| Oil resistant: complies with CNOMO E.03.40.150N, ASTM n.2, IRM 902, IEC60811-2-1 |
| UV resistant: complies with UL1581 |
| Resistance to flame spread: complies with IEC/EN60332-1 |
| IEC/EN 60079-14 (ATEX Ex II) |
| RoHS (CE): complies with 2015/863/EU |
| PART NUMBER : CMSB2200 |
| Unarmoured black cable, available by the metre (minimun order 10m (32.8ft)): 2 Ethernet cables, 3 power supply wires, 2 coaxial video cable, 15 wires for alarms, relays and telemetry |
| VIDEO |
| 2 coaxial cables, RG179 |
| I/O |
| Alarms, relay and telemetry |
| • Number of conductors: 15 |
| • Section: 0.34mm² (22AWG) |
| • Shielded cable |
