24/7 Monitoring in non-visible environment: Harnessing heat radiation for superior threat detection in challenging environments, this technology effectively penetrates total darkness, bright glare, deep shadows, smoke, and fog. By capturing clear images based on heat signatures, thermal cameras provide constant, reliable surveillance. The system enables security personnel to identify potential threats in conditions where traditional cameras and the human eye falter, ensuring uninterrupted monitoring in visually complex settings.
Enhance security with VCA detection: Elevate your security with our thermal camera's VCA system, featuring Object Classification that distinguishes between humans and vehicles. This advanced technology accurately detects intrusions, unauthorized crossings, and suspicious loitering while minimizing false alarms triggered by wildlife or environmental factors, significantly enhancing operational efficiency and ensuring rapid response to genuine threats across diverse settings.
Safeguard Assets with Temperature Measurement: Safeguard your critical assets and prevent disasters with our thermal camera's comprehensive protection suite, featuring precision temperature monitoring with instant alerts, early fire spot detection, and unauthorized smoking identification, empowering you to take immediate action against potential threats in various environments.
Features:
- Bi-spectrum Thermal with 256 x 192 thermal & 4MP
- NETD < 50 mK @ F1.0
- Video Analytics (Intrusion, Line Crossing)
- Object Classification, Trigger by human/vehicle
- Temperature Measurement & Alarms
| Camera Speci cations | - |
| Image Sensor | Dual sensor: Uncooled VOx Micro bolometer 1/2.7" Progressive CMOS |
| Max. Resolution | Thermal lens: Effective pixels: 256x192 Image scale up to: 704x576 Optical lens: 2880x1620 |
| Lens Type | Fixed-focal (Thermal lens) Fixed-focal (optical lens) |
| Focal Length | Thermal lens: f = 7 mm optical lens: f = 8 mm |
| Aperture | Thermal lens: F1.0 optical lens: F2.0 |
| Iris Type | Fixed iris |
| Field of View | Thermal lens (7mm) 24°(Horizontal) 18° (Vertical) optical lens (8mm) 40° (Horizontal) 20°(Vertical) |
| Illuminators | Built-in IR Illuminator up to 50 meters; White light for strobe light warning |
| Pan/Tilt/Zoom Functionalities | ePTZ: 4x digital zoom |
| Storage | MicroSD/SDHC/SDXC card (256GB capacity supported) |
| Pixel Size | 12 µm |
| Spectral Range | 8 ~ 14 µm |
| Sensitivity | NETD < 50 mK |
| Video | - |
| Compression | H.265, H.264, MJPEG |
| Maximum Frame Rate | Thermal: 25 fps @ 704x576 Optical: 25 fps @ 2880x1620 |
| Maximum Streams | 2 simultaneous streams each sensor |
| Main Stream | Thermal: 25fps@704x576 Optical: 25fps@2880x1620, 2560x1440, 2304x1296,1920x1080, 1280x720 |
| 2nd Stream | Thermal: 25fps@704x576 , 352x240, 256x192 Optical: 25fps@704x576 , 640x480 |
| Video Streaming | Adjustable resolution, CBR/VBR, Smart Encode |
| Image Settings | General settings video title and time stamp overlay, video orientation ( ip, mirror, rotation) Thermal settings white balance, image adjustment (brightness, contrast, sharpness) Privacy mask Scheduled pro le settings |
| Audio | - |
| Audio Capability | Two-way audio |
| Compression | G.711, RAW_PCM |
| Interface | External microphone input, External line output, Built-in speaker |
| Video | - |
| Compression | H.265, H.264, MJPEG |
| Maximum Frame Rate | Thermal: 25 fps @ 704x576 Optical: 25 fps @ 2880x1620 |
| Maximum Streams | 2 simultaneous streams each sensor |
| Main Stream | Thermal: 25fps@704x576 Optical: 25fps@2880x1620, 2560x1440, 2304x1296,1920x1080, 1280x720 |
| 2nd Stream | Thermal: 25fps@704x576 , 352x240, 256x192 Optical: 25fps@704x576 , 640x480 |
| Video Streaming | Adjustable resolution, CBR/VBR, Smart Encode |
| Image Settings | General settings video title and time stamp overlay, video orientation ( ip, mirror, rotation) Thermal settings white balance, image adjustment (brightness, contrast, sharpness) Privacy mask Scheduled pro le settings |
| Network | - |
| Users | Live viewing for up to 10 clients |
| Security | Access list, Password protection, user access log, user account management |
| Protocols | IPv4/IPv6, HTTP, RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, HTTPS, 802.1x, QOS, NTP, TCP/IP, FTP, UPnP, DDNS, ICMP, IGMP |
| Interface | 10 Base-T/100 Base-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
| ONVIF | Pro le G, S, T supported, speci cation available at www.onvif.org |
| AI Analytics | - |
| Compute Capability | SoC with built-in hardware deep learning accelerator (1T) |
| Application | Temperature measurement alarms (difference, threshold, section, rise), Early Fire Detection (Fire spot detection, Smoking detection, Smoke & ame detection) VCA (Intrusion, Single line crossing, Double line crossing, Loitering, Wrong way, Enter, Leave) Support VCA alarms triggering by person, car, person or car; Support temperature alarms triggering by ignoring person, car, person or car |
| Solution Integration | - |
| Video motion detection | Smart motion detection |
| Alarm and Event | - |
| Event Trigger | Motion detection, I/O alarm, Disk alarm, VCA alarm, Temperature alarm |
| Event Action | Event noti cation via audio clip, digital output, email, FTP, SD card; white light ashing and horn warning |
| Included Accessories | - |
| Packing Contents | Quick installation guide, alignment sticker, screw pack, waterproof accessory bag, junction box, sunshield |
| System Requirements | - |
| Operating System | Microsoft Windows 10/8/7 Mac 10.12 (Chrome only) |
| Web Browser | Chrome 58.0 or above Internet Explorer 10/11 |
| Other Players | VLC: 1.1.11 or above |
| Temperature Measurement | - |
| Temperature Range | -20°C to 150°C (-4°F to 302°F) |
| Measurement Rule | Point, line, polygon (up to 20 rules in total) |
| Temperature Alarm | Threshold alarm, Temperature difference alarm, Temperature rise alarm, Section alarm |
| Accuracy | ± 2°C / ±2% |
