System Overview
With an embedded face detection algorithm, the camera supports White/Black-list event alarm deployment under different scenarios. BioPro Series 4MP IP cameras provide a cost-efficient solution that is powered by cutting-edge technology for crystal-clear video monitoring.
The BioPro series also offers multiple industry-leading intelligent video analytic functions, such as Face Detection, Line Crossing, Intrusion, Object Left/Lost, Counting, for smart event alarms.
The P2P cloud function is built-in for every device, which is more convenient and flexible for remote real-time viewing.
Functions:
H.265+
H.265+ technology is an evolutionary optimization of H.265 and the traditional H.264. It includes a series of encoding strategies such as dynamic ROI, smart 2D&3D noise reduction for delivering high-quality videos, and significantly saving up to 70% bandwidth and storage.
Protection
With its precise mechanical and rugged metal casing design, IP cameras of the BioPro series rated IP67 could stand against water and dust for a long time. With 10% of input voltage tolerance, the cameras could work safely under extreme or unstable power conditions.
With a working temperature range from -30°C to 60°C, the cameras could adapt to a variety of harsh outdoor environments.
Features:
Camera | |
Model | BS-854N23C -E3 |
Image Sensor | 1/3” CMOS |
Effective Pixels | 2592*1520 |
Min. Illumination | Color: 0.01Lux@F2.0 (AGC ON) B/W: 0.001Lux@F2.0 (AGC ON) |
Flash / DDR | 1Gb / 2Gb |
IR LED No. | 2 (Smart IR) |
IR Distance | 30m |
S/N Ratio | >52dB |
Lens | |
Lens Type | Fixed |
Mount Type | Board-in |
Focal Length | 6mm |
Aperture | F2.0 |
FOV | 60° |
Optical Zoom | N/A |
Video | |
Compression | H.265+, H.265, H.264 |
Resolution | 4MP (2592 x 1520) / 3MP (2304 x 1296)/ 1080P (1920 x 1080) / 1.3MP (1280 x 960) / 720P (1280 x 720) |
Bitrate Control | CBR / VBR |
Bitrate | 1024Kbps ~ 4Mbps |
Multi-Streaming | Main Stream: 4MP@25fps / 3MP@25fps / 1080P@25fps / 960P@25fps / 720P@25FPS Sub Stream: D1@25fps / VGA@25fps / CIF@25fps Third Stream: N/A |
Motion Detection | Support |
Digital Zoom | Support |
Audio Compression | G7.11u |
Privacy Mask | 4 areas |
WDR | DWDR |
Day / Night | Support |
White Balance | Support |
Defog | N/A |
Noise Reduction | 2D/3D DNR |
Mirror/Flip | Support |
Corridor Mode | Support |
HLC | Support |
BLC | Support |
ROI | 4 areas |
Anti-flicker | Support |
IVA | |
Intelligent Video | Face Detection / Line Crossing / Area Detection / Target Count / Object Left / Lost/ VQD /Video Tampering |
Face Detection | |
Face Templates | N/A |
Face Detected Per Frame | 30 |
Detected Face Size | 80x80 ~ 300x300 Pixels |
Face Quality Filtering | Support |
Detection Area | User-defined |
Capture Response | ≤1s |
Network | |
Protocol | TCP/IP, UDP, HTTP, DHCP, RTSP, NTP |
Interoperability | ONVIF Profile S, SDK, API |
Max. Online Users | 5 |
Web Browser | IE / Firefox / Chrome / Safari |
Management Software (VMS) | AntarVis 2.0 / ZKBioSecurity IVS / BioAccess IVS |
Operation System | Windows |
Mobile APP | AntarView Pro |
P2P Cloud Service | Support |
Note: Video streaming is not available for Firefox / Chrome / Safari | |
Interface | |
Ethernet | 1 RJ-45 port (10/100Mbps) |
Audio I/O | N/A |
Alarm I/O | N/A |
RS485 | N/A |
Reset Button | N/A |
Micro-SD Slot | N/A |
ANR | N/A |
USB | N/A |
General | |
Power Supply | PoE (IEEE802.3af), DC 12V±10% |
Power Consumption | <3W |
Ingress Protection | IP67 |
Dimensions (L*W*H) | 170 * 75 * 66 (mm) |
Working Temperature | -30°C ~ 60°C |
Working Humidity | 10% ~ 90% |
Net Weight | 0.30kg |
Gross Weight | 0.45kg |
