CCT2U00 - 2 MP TVI Box Camera HD over Coax - IDIS
• 2 megapixel resolution (1080p)
• 1/2.8˝ Sony STARVIS CMOS image sensor
• Lens not included
• True day/night with IR cut filter
• Back Light Compensation (BLC)
• Digital Noise Reduction (DNR)
• Wide Dynamic Range (WDR)
• Up-the-coax control (UTC)
• 12VDC or 24VAC
| Power | |
|---|---|
| Source | 12 VDC or 24 VAC |
| Consumption | 120 mA @ 12 VDC, 80mA @ 24 VAC |
| Sensor | |
| Image Sensor | 1/2.8" HD CMOS |
| Scanning Mode | Progressive Scan |
| Resolution | 1920 x 1080 |
| Frame Rate | Up to 30 fps |
| Minimum Illumination | 0.4 Lux (AGC MAX, SENS-UP OFF, F2.0) (Color) 0.01 Lux (AGC MAX, SENS-UP OFF, F2.0) (B/W) |
| Dynamic Range | 120 dB (True WDR) |
| Shutter Speed | Auto / Flicker / Manual: 1/30 ~ 1/13,000 sec |
| S/N Ratio | More than 50 dB |
| Video Features | |
| Video Output | 1.0Vp-p, 75Ω Composite 1.0Vp-p, 75Ω TVI |
| Camera Functions | |
| Auto Gain Control | Yes |
| Auto White Balance | Yes |
| Back Light Compensation | Yes |
| Day / Night | Yes; IR Cut Filter |
| Digital Noise Reduction | Yes |
| Defog | Yes |
| Motion Detection | Yes; 4 Zones |
| Mirror | Yes |
| Flip | Yes |
| Privacy Masking | Box: 16 Zones; Polygon: 8 Zones |
| General Information | |
| Approvals | FCC |
| Operating Temperature | 14°F ~ +122°F (-10°C ~ +50°C) 20% ~ 80% RH |
| Storage Temperature | -4°F ~ +140°F (-20°C ~ +60°C) 20% ~ 95% RH |
| Dimensions (W x H x L) | 1.97" x 2.24" x 4.07" (50 mm x 56.8 mm x 103.4 mm) |
| Weight | 0.53 lbs (0.24 kg) |
The CCT2U00 is a 2MP (1920x1080) HD over Coax box camera designed for analog surveillance systems using TVI (High Definition Transport Video Interface) technology. It features a 1/2.8" HD CMOS sensor with progressive scan, providing a frame rate of up to 30 fps. The camera delivers strong low-light performance with a minimum illumination of 0.4 lux (color) / 0.01 lux (B/W) and features 120dB True WDR for handling challenging lighting. It includes essential camera functions like Day/Night (with IR cut filter), Digital Noise Reduction (DNR), Defog, Motion Detection, and Privacy Masking. It outputs video in both standard composite (CVBS) and HD-TVI formats simultaneously over coaxial cable. It can be powered by either 12V DC or 24V AC. The camera operates within a temperature range of -10°C to 50°C (14°F to 122°F) and 20-80% humidity.
