- • 2 megapixel resolution (1080p)
- • 2.8 mm fixed lens
- • 1/2.9″ Sony CMOS image sensor
- • 18 IR LEDs with a 50 foot (15m) range
- • Back Light Compensation (BLC)
- • Wide Dynamic Range (WDR)
- • Up-the-Coax camera control (UTC)
- • IP66 weatherproof rated
- • 12VDC
| Power | |
| Source | 12VDC |
| Consumption | 3.5 watts (292mA) |
| Camera Functions | |
| Day & Night | Yes, IR Cut Filter |
| Digital Noise Reduction | 2D |
| Wide Dynamic Range | dWDR |
| Max Distance | 985 Feet (100m) |
| Video Output | AHD/TVI/CVI/CVBS |
| Sensor and General Information | |
| Image Sensor | 1/2.9” Sony CMOS |
| Signal System | PAL/NTSC |
| Resolution (H x V) | 1920x1080 |
| Lens Focal Length | 2.8mm |
| Iris Control | Auto Iris |
| Frame Rate | PAL:25fps ,NTSC:30fps |
| IR LED | 18pcs |
| IR Wavelength | 850nm |
| IR Range | 50 Feet (15m) Range |
| Color | 0.01Lux(AGC ON); IR ON 0 Lux |
| Shutter Speed | PAL:1/50-1/50000, NTSC:1/60-1/60000 |
| S/N Ratio | More than 50dB |
| Up the Coax | Pelco C, UTC (H) |
| IP Rating | IP66 |
| Humidity | 85% RH Max |
| Temperature | 14°F to 131°F (-10°C to 55°C) |
| Dimensions | 3.70˝ x 3.30˝(94 x 84mm) |
| Weight | 0.793 lbs. (360g) |
| Approvals | FCC, CE |
This is a Full HD analog HD bullet camera designed for outdoor surveillance. It uses a 1/2.9-inch Sony CMOS sensor to provide 1920x1080 resolution and is equipped with a wide-angle 2.8mm fixed lens. It supports multiple analog HD formats, including AHD, TVI, CVI, and standard CVBS, with video transmission possible up to 100 meters. For low-light performance, it includes 18 infrared LEDs with an 850nm wavelength, offering an effective illumination range of 15 meters. It can produce a color image down to 0.01 lux and a black-and-white image at 0 lux with the IR on. The camera features Digital Wide Dynamic Range (dWDR) and 2D Digital Noise Reduction to handle challenging lighting. Housed in an IP66-rated weatherproof enclosure, it operates in temperatures from -10°C to 55°C. It is powered by a 12VDC source with a low power consumption of 3.5 watts.
