VideoTec - UPKT3AFSAN00AH - ULISSE RADICAL THERMAL PTZ Full IP, H.264, Onvif-S, 120Vac, thermal camera optical zoom 3x (digital zoom 8x), 640X512, 25-30Hz
Part number:
UPKT3AFSAN00AH
Price:
ULISSE RADICAL THERMAL is the first Videotec ready-to-use thermal PTZ camera system that integrates exceptional factory-assembled combinations of lens and thermal camera for unsurpassed intrusion detection and visual awareness in total darkness or extreme environmental conditions.
Features:
- Continuous zoom lens, 3x thermal optics, 35-105mm and digital zoom up to 8x, 24x total zoom
- Advanced Autofocus system
- Analogue or IP (ONVIF S) versions
- Advanced Thermographic Function (STR, Spot Temperature Reading)
- DDE, Digital Detail Enhancement
- Dynamic adjustment of contrast (ACE, Active Contrast Enhancement)
- Operating temperature: from -40°C (-40°F) up to +65°C (149°F)
| GENERAL |
| Constructed from aluminium and tecnopolymer |
| Epoxypolyester powder painting, RAL9002 colour |
| Top mount (OTT) |
| Transmission through toothed belt |
| Slip-ring |
| Electronic limit switches |
| Zero backlash |
| Pre-installed camera and lens |
| MECHANICAL |
| Cable glands: 3xM16 |
| Horizontal rotation: 360°, continuous rotation |
| Vertical rotation: from -40° up to +90° |
| Horizontal speed (variable): from 0.02°/s up to 100°/s |
| Tilt speed (variable): from 0.02°/s up to 50°/s |
| Internal usable area (WxHxL): 90x115x325mm (3.5x4.5x13in) |
| Accuracy of preset positions: 0.02° |
| Unit weight: 17kg (37lb) |
| HOUSING'S WINDOW |
| Germanium window |
| Thick: 4mm (0.16in) |
| External treatment: antiscratch (Hard Carbon Coating - DLC), antireflection |
| Internal treatment: antireflection |
| Spectral range: from 7.5μm up to 14μm |
