- • 2 megapixel resolution (1080p)
- • 3.6 mm fixed lens
- • 1/2.8″ Sony CMOS image sensor
- • 12 IR LEDs with a 33 foot range
- • Back Light Compensation (BLC)
- • True Wide Dynamic Range (TWDR)
- • Up-the-Coax camera control (UTC)
- • IP66 weatherproof rated
- • 12VDC
| Power | |
| Source | 12VDC |
| Consumption | 3.5 watts (292mA) |
| Camera Functions | |
| Day & Night | Yes, IR Cut Filter |
| Digital Noise Reduction | 2D |
| Wide Dynamic Range | TWDR |
| Max Distance | 985 Feet (100m) |
| Video Output | AHD/TVI/CVI/CVBS |
| Sensor and General Information | |
| Image Sensor | 1/2.9” Sony CMOS |
| Signal System | PAL/NTSC |
| Resolution (H x V) | 1920x1080 |
| Lens Focal Length | 3.6mm |
| Iris Control | Auto Iris |
| Frame Rate | PAL:25fps ,NTSC:30fps |
| IR LED | 12pcs |
| IR Wavelength | 850nm |
| IR Range | 33 Feet Range |
| Color | 0.01Lux(AGC ON); IR ON 0 Lux |
| Shutter Speed | PAL:1/50-1/50000, NTSC:1/60-1/60000 |
| S/N Ratio | More than 50dB |
| Up the Coax | Pelco C, UTC (H) |
| IP Rating | IP66 |
| Humidity | 85% RH Max |
| Temperature | 14°F to 131°F (-10°C to 55°C) |
| Dimensions | 2.32” x 2.20” H |
| Weight | 0.793 lbs. (360g) |
| Approvals | FCC, CE |
This is a Full HD analog HD bullet camera designed for outdoor surveillance. It uses a 1/2.9-inch Sony CMOS sensor to provide 1920x1080 resolution and features a 3.6mm fixed lens. It supports multiple analog HD formats, including AHD, TVI, CVI, and standard CVBS, with video transmission possible up to 100 meters. For operation in low light, it includes 12 infrared LEDs with an 850nm wavelength, providing an effective illumination range of 10 meters (33 feet). It can produce a color image down to 0.01 lux and a black-and-white image at 0 lux with the IR on. The camera features True Wide Dynamic Range and 2D Digital Noise Reduction to manage challenging lighting conditions. Housed in an IP66-rated weatherproof enclosure, it operates in temperatures from -10°C to 55°C. It is powered by a 12VDC source with a low power consumption of 3.5 watts.
